What we know about the measurement:
- Quality of the measurement data is
unknown.
-
Origin of the data is Novacoustic.
-
Format of the data is
a GLL file
.
-
-3dB (resp. -6db) point v.s. reference is at 61.5Hz (resp. 58.0Hz).
-
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 27.8dB over the same frequency range.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for toursound speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is -0.47
and would be 2.23 with a
perfect subwoofer.
- Details:
NBD: ON 1.532,
LW 1.068, SP
1.115, PIR
0.958; SM:
SP0.585,
PIR0.53; LFQ
3.699, LFX 61Hz
- Tonality (Preference) Score is 1.26
with an EQ and would be 3.92 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 1.304,
LW 0.879, SP
0.93, PIR
0.778; SM:
SP0.795,
PIR0.782; LFQ 3.699, LFX 60Hz
-
Vendor specifications:
- Dispersion: 110° horizontal and 50° vertical.
- Sensitivity 112 dB
- Impedance 2 Ohm
- SPL
- Size
- Width 560mm
- Height 800mm
- Depth 570mm
- Weight 60.0kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -1.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
56.0 |
2.93 |
2.96 |
| PK |
98.0 |
2.08 |
-2.89 |
| PK |
184.0 |
0.32 |
-4.17 |
| PK |
540.0 |
2.98 |
-1.84 |
| PK |
2670.0 |
2.49 |
3.0 |
| PK |
5536.0 |
1.64 |
-8.67 |
| PK |
11476.0 |
2.72 |
-6.51 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
-0.75 |
| PK |
160.0 |
2.14 |
-0.5 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.25 |
| PK |
1000.0 |
2.14 |
0.5 |
| PK |
1600.0 |
2.14 |
0.5 |
| PK |
2500.0 |
2.14 |
1.25 |
| PK |
4000.0 |
2.14 |
0.5 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.0 |
| PK |
80.0 |
4.32 |
-0.5 |
| PK |
100.0 |
4.32 |
-0.75 |
| PK |
125.0 |
4.32 |
-0.5 |
| PK |
160.0 |
4.32 |
-0.5 |
| PK |
200.0 |
4.32 |
-0.5 |
| PK |
250.0 |
4.32 |
-0.5 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
-0.25 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.25 |
| PK |
1600.0 |
4.32 |
0.25 |
| PK |
2000.0 |
4.32 |
0.5 |
| PK |
2500.0 |
4.32 |
1.5 |
| PK |
3150.0 |
4.32 |
0.75 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
1.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.5 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
