We have multiple measurements for this speaker. Click here to see the default one (which is higher quality if we have one measurement better than the others).
- Quality of the measurement data is medium.
- Origin of the data is K ARRAY.
- Format of the data is a GLL file .
- -3dB (resp. -6db) point v.s. reference is at 112.0Hz (resp. 109.0Hz).
- Reference level is normalised to -0.1dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 4.7dB over the same frequency range.
- Directivity
- Horizontal directivity is (-30.0°, 30.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-30.0°, 30.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is -4.6
and would be -0.73 with a
perfect subwoofer.
- Details: NBD: ON 1.618, LW 1.45, SP 1.516, PIR 1.47; SM: SP0.03, PIR0.006; LFQ 4.794, LFX 115Hz
- Tonality (Preference) Score is -3.19
with an EQ and would be 0.73 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 1.429, LW 1.254, SP 1.374, PIR 1.304; SM: SP0.026, PIR0.221; LFQ 4.794, LFX 118Hz
- Tonality (Preference) Score is -4.6
and would be -0.73 with a
perfect subwoofer.
