What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is FBT.
-
Format of the data is
a GLL file
.
-
-3dB (resp. -6db) point v.s. reference is at 48.7Hz (resp. 45.0Hz).
-
Reference level is normalised to -0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 4.6dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 0.18
and would be 2.45 with a
perfect subwoofer.
- Details:
NBD: ON 0.957,
LW 0.993, SP
1.02, PIR
1.003; SM:
SP0.237,
PIR0.065; LFQ
4.116, LFX 48Hz
- Tonality (Preference) Score is 2.18
with an EQ and would be 4.56 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.708,
LW 0.719, SP
0.781, PIR
0.733; SM:
SP0.59,
PIR0.358; LFQ 4.116, LFX 51Hz
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.9dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
38.0 |
1.88 |
3.0 |
| 3 |
65.0 |
2.27 |
-7.68 |
| 3 |
67.0 |
0.84 |
2.66 |
| 3 |
504.0 |
0.61 |
-2.24 |
| 3 |
1642.0 |
1.32 |
2.99 |
| 3 |
2168.0 |
3.0 |
3.0 |
| 3 |
12301.0 |
0.5 |
-8.99 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
AutomaticEQ LW (IIR)
|
|
Set preamp gain to: -6.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
66.0 |
2.46 |
-2.91 |
| 3 |
447.0 |
2.65 |
-2.66 |
| 3 |
1491.0 |
2.32 |
2.96 |
| 3 |
2226.0 |
2.74 |
2.88 |
| 3 |
2631.0 |
0.7 |
2.95 |
| 3 |
13092.0 |
0.56 |
-2.98 |
| 3 |
14965.0 |
2.62 |
-2.89 |
|
Download
|
These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
|
AutomaticEQ Score (IIR)
|
|
Set preamp gain to: -6.5dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
78.0 |
1.42 |
-2.98 |
| 3 |
109.0 |
3.0 |
2.98 |
| 3 |
432.0 |
3.0 |
-2.41 |
| 3 |
1442.0 |
2.13 |
3.0 |
| 3 |
2153.0 |
1.99 |
3.0 |
| 3 |
2153.0 |
2.95 |
2.99 |
| 3 |
12662.0 |
0.45 |
-3.0 |
|
Download
|
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
-0.25 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.25 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.25 |
| 3 |
1000.0 |
2.14 |
0.25 |
| 3 |
1600.0 |
2.14 |
1.0 |
| 3 |
2500.0 |
2.14 |
0.75 |
| 3 |
4000.0 |
2.14 |
0.5 |
| 3 |
6300.0 |
2.14 |
0.0 |
| 3 |
10000.0 |
2.14 |
-0.5 |
| 3 |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.5 |
| 3 |
31.0 |
4.32 |
0.5 |
| 3 |
40.0 |
4.32 |
0.5 |
| 3 |
50.0 |
4.32 |
0.5 |
| 3 |
63.0 |
4.32 |
-0.25 |
| 3 |
80.0 |
4.32 |
0.25 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
0.25 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.25 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.25 |
| 3 |
800.0 |
4.32 |
0.25 |
| 3 |
1000.0 |
4.32 |
0.25 |
| 3 |
1250.0 |
4.32 |
0.75 |
| 3 |
1600.0 |
4.32 |
1.0 |
| 3 |
2000.0 |
4.32 |
1.25 |
| 3 |
2500.0 |
4.32 |
0.75 |
| 3 |
3150.0 |
4.32 |
0.75 |
| 3 |
4000.0 |
4.32 |
0.75 |
| 3 |
5000.0 |
4.32 |
0.25 |
| 3 |
6300.0 |
4.32 |
0.25 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
-0.25 |
| 3 |
16000.0 |
4.32 |
-0.5 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
