What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is BiAmp.
-
Format of the data is
a GLL file
.
-
Sensitivity:
-
Sensitivity: 89.1dB (avg. 100Hz-1kHz for 2.83V estimated at 1m).
-
Sensitivity: 69.1dB computed at the measurement distance (10.0m) over the same frequency range.
-
-3dB (resp. -6db) point v.s. reference is at 100.0Hz (resp. 82.5Hz).
-
Reference level is normalised to 0.4dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 4.5dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is -0.63
and would be 2.73 with a
perfect subwoofer.
- Details:
NBD: ON 1.1,
LW 0.984, SP
1.012, PIR
0.98; SM:
SP0.62,
PIR0.312; LFQ
1.203, LFX 87Hz
- Tonality (Preference) Score is 2.01
with an EQ and would be 4.87 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.907,
LW 0.772, SP
0.866, PIR
0.799; SM:
SP0.864,
PIR0.794; LFQ 1.164, LFX 67Hz
-
Note: data computed at 2 meters..
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.5dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
342.0 |
0.37 |
2.53 |
| PK |
565.0 |
1.04 |
-2.1 |
| PK |
714.0 |
2.98 |
2.98 |
| PK |
1180.0 |
2.98 |
2.97 |
| PK |
1822.0 |
2.12 |
-2.77 |
| PK |
2721.0 |
2.89 |
2.89 |
| PK |
5135.0 |
0.62 |
-2.54 |
| PK |
6489.0 |
0.83 |
-2.94 |
| NO |
9372.0 |
30.0 |
-0.35 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.75 |
| PK |
40.0 |
2.14 |
0.75 |
| PK |
63.0 |
2.14 |
0.75 |
| PK |
100.0 |
2.14 |
0.75 |
| PK |
160.0 |
2.14 |
0.25 |
| PK |
250.0 |
2.14 |
0.75 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.5 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
0.5 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.5 |
| PK |
16000.0 |
2.14 |
1.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.5 |
| PK |
100.0 |
4.32 |
0.5 |
| PK |
125.0 |
4.32 |
0.25 |
| PK |
160.0 |
4.32 |
0.25 |
| PK |
200.0 |
4.32 |
0.5 |
| PK |
250.0 |
4.32 |
0.5 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.5 |
| PK |
1250.0 |
4.32 |
0.75 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
-0.25 |
| PK |
2500.0 |
4.32 |
0.5 |
| PK |
3150.0 |
4.32 |
0.5 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
0.25 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
0.25 |
| PK |
10000.0 |
4.32 |
-0.25 |
| PK |
12000.0 |
4.32 |
0.25 |
| PK |
16000.0 |
4.32 |
1.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
