What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 84.1dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 48.3Hz (resp. 43.9Hz).
-
Reference level is normalised to -0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 5.4dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.27
and would be 6.14 with a
perfect subwoofer.
- Details:
NBD: ON 0.808,
LW 0.641, SP
0.433, PIR
0.446; SM:
SP0.914,
PIR0.782; LFQ
1.504, LFX 39Hz
- Tonality (Preference) Score is 5.89
with an EQ and would be 7.38 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.579,
LW 0.415, SP
0.348, PIR
0.282; SM:
SP0.92,
PIR0.858; LFQ 1.545, LFX 32Hz
-
Link to original Review: eac review.
Links to other reviews: yt review
.
AutomaticEQ (IIR)
|
Set preamp gain to: -4.6dB.
|
Type |
Freq |
Q |
Gain |
PK |
32.0 |
2.81 |
3.0 |
PK |
49.0 |
0.6 |
2.0 |
PK |
289.0 |
2.02 |
-2.26 |
PK |
470.0 |
3.0 |
2.99 |
PK |
1010.0 |
2.94 |
2.99 |
PK |
1121.0 |
3.0 |
-5.16 |
PK |
4342.0 |
3.0 |
-2.8 |
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
Graphic EQ 15 bands
|
Set preamp gain to: -0.6dB.
|
Type |
Freq |
Q |
Gain |
PK |
25.0 |
2.14 |
0.5 |
PK |
40.0 |
2.14 |
0.5 |
PK |
63.0 |
2.14 |
0.25 |
PK |
100.0 |
2.14 |
0.0 |
PK |
160.0 |
2.14 |
0.0 |
PK |
250.0 |
2.14 |
-0.25 |
PK |
400.0 |
2.14 |
0.0 |
PK |
630.0 |
2.14 |
0.0 |
PK |
1000.0 |
2.14 |
-0.25 |
PK |
1600.0 |
2.14 |
-0.25 |
PK |
2500.0 |
2.14 |
0.0 |
PK |
4000.0 |
2.14 |
0.0 |
PK |
6300.0 |
2.14 |
0.25 |
PK |
10000.0 |
2.14 |
0.0 |
PK |
16000.0 |
2.14 |
0.5 |
Download
|
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
|
Set preamp gain to: -0.7dB.
|
Type |
Freq |
Q |
Gain |
PK |
20.0 |
4.32 |
0.0 |
PK |
25.0 |
4.32 |
0.5 |
PK |
31.0 |
4.32 |
0.5 |
PK |
40.0 |
4.32 |
0.5 |
PK |
50.0 |
4.32 |
0.5 |
PK |
63.0 |
4.32 |
0.25 |
PK |
80.0 |
4.32 |
0.25 |
PK |
100.0 |
4.32 |
0.0 |
PK |
125.0 |
4.32 |
0.0 |
PK |
160.0 |
4.32 |
0.0 |
PK |
200.0 |
4.32 |
-0.25 |
PK |
250.0 |
4.32 |
-0.25 |
PK |
315.0 |
4.32 |
-0.25 |
PK |
400.0 |
4.32 |
0.25 |
PK |
500.0 |
4.32 |
0.5 |
PK |
630.0 |
4.32 |
0.25 |
PK |
800.0 |
4.32 |
0.25 |
PK |
1000.0 |
4.32 |
0.0 |
PK |
1250.0 |
4.32 |
-0.25 |
PK |
1600.0 |
4.32 |
-0.25 |
PK |
2000.0 |
4.32 |
-0.25 |
PK |
2500.0 |
4.32 |
0.0 |
PK |
3150.0 |
4.32 |
0.5 |
PK |
4000.0 |
4.32 |
0.0 |
PK |
5000.0 |
4.32 |
0.25 |
PK |
6300.0 |
4.32 |
0.25 |
PK |
8000.0 |
4.32 |
0.25 |
PK |
10000.0 |
4.32 |
0.25 |
PK |
12000.0 |
4.32 |
0.25 |
PK |
16000.0 |
4.32 |
0.5 |
PK |
20000.0 |
4.32 |
0.0 |
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
