We have multiple measurements for this speaker. Click here to see the default one (which is higher quality if we have one measurement better than the others).
- Quality of the measurement data is high.
- Origin of the data is ASR.
- Format of the data is generated by a Klippel NFS .
- -3dB (resp. -6db) point v.s. reference is at 85.0Hz (resp. 63.0Hz).
- Reference level is normalised to 0.1dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 3.0dB over the same frequency range.
- Directivity
- Horizontal directivity is (-20.0°, 20.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-50.0°, 60.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.81
and would be 6.42 with a
perfect subwoofer.
- Details: NBD: ON 0.512, LW 0.42, SP 0.531, PIR 0.406; SM: SP0.754, PIR0.532; LFQ 0.944, LFX 58Hz
- Tonality (Preference) Score is 5.77
with an EQ and would be 8.02 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.423, LW 0.307, SP 0.382, PIR 0.263; SM: SP0.947, PIR0.94; LFQ 0.944, LFX 48Hz
- Tonality (Preference) Score is 3.81
and would be 6.42 with a
perfect subwoofer.
- Horizontal measurement
- Link to Original review.
