What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 85.4dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 79.8Hz (resp. 74.0Hz).
-
Reference level is normalised to 0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 4.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 2.73
and would be 5.72 with a
perfect subwoofer.
- Details:
NBD: ON 0.639,
LW 0.575, SP
0.489, PIR
0.47; SM:
SP0.812,
PIR0.448; LFQ
0.274, LFX 71Hz
- Tonality (Preference) Score is 4.87
with an EQ and would be 7.8 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.427,
LW 0.349, SP
0.349, PIR
0.281; SM:
SP0.93,
PIR0.875; LFQ 0.274, LFX 69Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
79.0 |
0.45 |
1.04 |
| 3 |
418.0 |
2.81 |
1.01 |
| 3 |
844.0 |
2.85 |
2.94 |
| 3 |
1032.0 |
2.81 |
-2.78 |
| 3 |
1762.0 |
2.12 |
2.94 |
| 3 |
2461.0 |
2.55 |
-2.56 |
| 3 |
3676.0 |
2.9 |
2.09 |
| 3 |
4803.0 |
2.98 |
-2.96 |
| 3 |
9372.0 |
0.48 |
-1.84 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -3.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
445.0 |
5.0 |
1.1 |
| 3 |
844.0 |
5.0 |
2.2 |
| 3 |
971.0 |
5.0 |
-3.7 |
| 3 |
1078.0 |
1.0 |
-1.0 |
| 3 |
1736.0 |
1.143 |
6.3 |
| 3 |
1800.0 |
15.0 |
-0.5 |
| 3 |
1952.0 |
5.0 |
1.9 |
| 3 |
2080.0 |
20.0 |
-0.9 |
| 3 |
2112.0 |
1.309 |
-5.9 |
| 3 |
2220.0 |
20.0 |
1.0 |
| 3 |
3587.0 |
5.0 |
1.8 |
| 3 |
5440.0 |
1.686 |
-4.0 |
| 3 |
5812.0 |
5.0 |
3.2 |
| 3 |
7989.0 |
5.0 |
4.8 |
| 3 |
8885.0 |
2.227 |
-10.0 |
| 3 |
8893.0 |
5.0 |
2.9 |
| 3 |
9600.0 |
5.0 |
5.1 |
| 3 |
13048.0 |
5.0 |
-3.0 |
| 3 |
15869.0 |
5.0 |
1.9 |
| 3 |
16860.0 |
5.0 |
3.2 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
-0.25 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
-0.75 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
-0.5 |
| 3 |
4000.0 |
2.14 |
-0.5 |
| 3 |
6300.0 |
2.14 |
-0.75 |
| 3 |
10000.0 |
2.14 |
-0.5 |
| 3 |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
0.25 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.25 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
0.25 |
| 3 |
1000.0 |
4.32 |
-0.5 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
-0.25 |
| 3 |
2500.0 |
4.32 |
-0.5 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
-0.25 |
| 3 |
5000.0 |
4.32 |
-0.75 |
| 3 |
6300.0 |
4.32 |
-0.5 |
| 3 |
8000.0 |
4.32 |
-0.5 |
| 3 |
10000.0 |
4.32 |
-0.5 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
0.25 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
