We have multiple measurements for this speaker. Click here to see the default one (which is higher quality if we have one measurement better than the others).
- Quality of the measurement data is high.
- Origin of the data is ErinsAudioCorner.
- Format of the data is generated by a Klippel NFS .
- -3dB (resp. -6db) point v.s. reference is at 90.8Hz (resp. 63.0Hz).
- Reference level is normalised to -0.2dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 3.0dB over the same frequency range.
- Directivity
- Horizontal directivity is (-50.0°, 40.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-50.0°, 40.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.21
and would be 6.96 with a
perfect subwoofer.
- Details: NBD: ON 0.468, LW 0.391, SP 0.386, PIR 0.356; SM: SP0.841, PIR0.651; LFQ 0.948, LFX 62Hz
- Tonality (Preference) Score is 5.44
with an EQ and would be 8.05 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.385, LW 0.309, SP 0.289, PIR 0.258; SM: SP0.96, PIR0.908; LFQ 0.948, LFX 58Hz
- Tonality (Preference) Score is 4.21
and would be 6.96 with a
perfect subwoofer.
- Horizontal measurement
- Link to original Review: eac review. Links to other reviews: yt review .
