What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 90.1dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 58.6Hz (resp. 46.9Hz).
-
Reference level is normalised to -0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.7dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.43
and would be 5.63 with a
perfect subwoofer.
- Details:
NBD: ON 0.538,
LW 0.437, SP
0.359, PIR
0.376; SM:
SP0.715,
PIR0.178; LFQ
0.493, LFX 46Hz
- Tonality (Preference) Score is 6.29
with an EQ and would be 8.1 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.392,
LW 0.314, SP
0.337, PIR
0.264; SM:
SP0.955,
PIR0.942; LFQ 0.493, LFX 38Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
42.0 |
1.32 |
2.93 |
| 3 |
219.0 |
0.77 |
2.14 |
| 3 |
792.0 |
0.49 |
-2.18 |
| 3 |
849.0 |
2.99 |
3.0 |
| 3 |
2023.0 |
0.85 |
2.24 |
| 3 |
7059.0 |
1.36 |
2.69 |
| 3 |
12301.0 |
0.34 |
-5.45 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
332.0 |
20.0 |
-0.8 |
| 3 |
381.0 |
15.0 |
-0.6 |
| 3 |
428.0 |
10.0 |
-1.2 |
| 3 |
533.0 |
5.0 |
-0.6 |
| 3 |
666.0 |
1.697 |
-1.9 |
| 3 |
909.0 |
4.998 |
11.5 |
| 3 |
937.0 |
4.993 |
-9.8 |
| 3 |
1305.0 |
10.0 |
-1.0 |
| 3 |
1389.0 |
3.0 |
-1.3 |
| 3 |
1580.0 |
10.0 |
-0.7 |
| 3 |
2085.0 |
20.0 |
-0.9 |
| 3 |
2653.0 |
4.6 |
-1.2 |
| 3 |
4409.0 |
1.5 |
-1.3 |
| 3 |
6710.0 |
8.5 |
-0.5 |
| 3 |
10462.0 |
1.0 |
-4.4 |
| 3 |
13550.0 |
10.0 |
0.9 |
| 3 |
14650.0 |
8.0 |
-1.4 |
| 3 |
15843.0 |
1.0 |
-5.7 |
| 3 |
16600.0 |
3.8 |
1.3 |
| 3 |
19850.0 |
2.4 |
-3.2 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
0.5 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
0.25 |
| 3 |
250.0 |
2.14 |
0.25 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
-0.5 |
| 3 |
1600.0 |
2.14 |
0.0 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
-0.25 |
| 3 |
10000.0 |
2.14 |
-0.75 |
| 3 |
16000.0 |
2.14 |
-0.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.5 |
| 3 |
31.0 |
4.32 |
0.5 |
| 3 |
40.0 |
4.32 |
0.5 |
| 3 |
50.0 |
4.32 |
0.5 |
| 3 |
63.0 |
4.32 |
0.5 |
| 3 |
80.0 |
4.32 |
0.25 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
0.25 |
| 3 |
160.0 |
4.32 |
0.25 |
| 3 |
200.0 |
4.32 |
0.25 |
| 3 |
250.0 |
4.32 |
0.25 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
-0.5 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.0 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
-0.5 |
| 3 |
10000.0 |
4.32 |
-0.75 |
| 3 |
12000.0 |
4.32 |
-0.75 |
| 3 |
16000.0 |
4.32 |
-0.75 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
