We have multiple measurements for this speaker. Click here to see the default one (which is higher quality if we have one measurement better than the others).
- Quality of the measurement data is high.
- Origin of the data is ASR.
- Format of the data is generated by a Klippel NFS .
- -3dB (resp. -6db) point v.s. reference is at 71.8Hz (resp. 58.6Hz).
- Reference level is normalised to 0.0dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 2.8dB over the same frequency range.
- Directivity
- Horizontal directivity is (-60.0°, 50.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-20.0°, 20.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.66
and would be 7.13 with a
perfect subwoofer.
- Details: NBD: ON 0.488, LW 0.449, SP 0.388, PIR 0.356; SM: SP0.908, PIR0.748; LFQ 0.364, LFX 54Hz
- Tonality (Preference) Score is 5.42
with an EQ and would be 7.67 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.434, LW 0.392, SP 0.364, PIR 0.323; SM: SP0.92, PIR0.878; LFQ 0.364, LFX 48Hz
- Tonality (Preference) Score is 4.66
and would be 7.13 with a
perfect subwoofer.
- Link to Original review.
