We have multiple measurements for this speaker. Click
here to
see the default one (which is higher quality if we have one
measurement better than the others).
- Quality of the measurement data is high .
- Origin of the data is Bose.
- Format of the data is a GLL file .
- Sensitivity: 90.4dB (avg. 100Hz-1kHz for 2.83V measured at 10m)
- -3dB (resp. -6db) point v.s. reference is at 56.0Hz (resp. 51.5Hz).
- Reference level is normalised to -0.2dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 3.6dB over the same frequency range.
- Directivity
- Horizontal directivity is (-30.0°, 20.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-10.0°, 10.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 1.61
and would be 3.92 with a
perfect subwoofer.
- Details: NBD: ON 0.803, LW 0.748, SP 0.76, PIR 0.753; SM: SP0.482, PIR0.214; LFQ 2.024, LFX 49Hz
- Tonality (Preference) Score is 4.61
with an EQ and would be 6.93 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.532, LW 0.439, SP 0.529, PIR 0.466; SM: SP0.902, PIR0.849; LFQ 2.024, LFX 49Hz
- Tonality (Preference) Score is 1.61
and would be 3.92 with a
perfect subwoofer.
- .
-
Vendor specifications:
- Dispersion: 60° horizontal and 10° vertical.
- Sensitivity 100 dB
- Impedance 8 Ohm
- SPL
- peak: 129 dB
- Size
- Width 783mm
- Height 409mm
- Depth 420 mm)
- Weight 36.3 kg
