What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 86.0dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 85.7Hz (resp. 56.4Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.24
and would be 6.57 with a
perfect subwoofer.
- Details:
NBD: ON 0.579,
LW 0.495, SP
0.443, PIR
0.431; SM:
SP0.869,
PIR0.701; LFQ
0.404, LFX 50Hz
- Tonality (Preference) Score is 6.1
with an EQ and would be 8.05 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.396,
LW 0.358, SP
0.282, PIR
0.28; SM:
SP0.963,
PIR0.947; LFQ 0.486, LFX 41Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -4.5dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
85.0 |
0.86 |
2.98 |
| PK |
418.0 |
2.94 |
-1.31 |
| PK |
790.0 |
2.98 |
-2.63 |
| PK |
1220.0 |
1.78 |
-1.28 |
| PK |
2082.0 |
2.48 |
-0.56 |
| PK |
4492.0 |
2.28 |
-2.93 |
| PK |
6709.0 |
2.96 |
-1.47 |
| PK |
9691.0 |
2.26 |
-1.83 |
| LS |
16000.0 |
0.86 |
1.48 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
350.0 |
12.0 |
3.1 |
| PK |
376.0 |
20.0 |
-1.4 |
| PK |
400.0 |
4.892 |
-1.8 |
| PK |
526.0 |
5.0 |
0.8 |
| PK |
580.0 |
5.0 |
-1.8 |
| PK |
620.0 |
5.0 |
2.8 |
| PK |
731.0 |
3.826 |
-3.9 |
| PK |
948.0 |
4.992 |
-1.6 |
| PK |
1337.0 |
5.0 |
-1.7 |
| PK |
1815.0 |
30.0 |
-0.7 |
| PK |
2078.0 |
5.0 |
-3.8 |
| PK |
2113.0 |
2.064 |
5.0 |
| PK |
2425.0 |
5.0 |
-2.4 |
| PK |
4457.0 |
1.365 |
-1.8 |
| PK |
5659.0 |
5.0 |
1.4 |
| PK |
6700.0 |
8.0 |
-0.7 |
| PK |
7610.0 |
10.0 |
1.0 |
| PK |
8470.0 |
15.0 |
-0.8 |
| PK |
8568.0 |
5.0 |
-1.1 |
| PK |
9500.0 |
8.0 |
0.9 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
-0.25 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.25 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.5 |
| PK |
100.0 |
4.32 |
0.25 |
| PK |
125.0 |
4.32 |
0.25 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
