What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 82.9dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 70.3Hz (resp. 46.9Hz).
-
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-80.0°, 70.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-40.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.57
and would be 7.76 with a
perfect subwoofer.
- Details:
NBD: ON 0.412,
LW 0.348, SP
0.364, PIR
0.291; SM:
SP0.88,
PIR0.855; LFQ
0.717, LFX 46Hz
- Tonality (Preference) Score is 6.51
with an EQ and would be 8.46 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.327,
LW 0.288, SP
0.284, PIR
0.204; SM:
SP0.945,
PIR0.952; LFQ 0.717, LFX 41Hz
- Link to Original review.
AutomaticEQ (IIR)
|
Set preamp gain to: -3.0dB.
|
Type |
Freq |
Q |
Gain |
5 |
113.0 |
0.95 |
3.0 |
3 |
207.0 |
0.97 |
-0.65 |
3 |
739.0 |
0.84 |
1.46 |
3 |
873.0 |
3.0 |
-2.45 |
3 |
2813.0 |
2.13 |
-1.36 |
3 |
4803.0 |
2.57 |
-1.62 |
3 |
6709.0 |
1.88 |
1.05 |
3 |
8478.0 |
1.15 |
0.22 |
3 |
10020.0 |
1.11 |
0.11 |
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
flipflop@ASR (IIR)
|
Set preamp gain to: -2.2dB.
|
Type |
Freq |
Q |
Gain |
3 |
427.0 |
4.5 |
0.6 |
3 |
491.0 |
20.0 |
-0.5 |
3 |
533.0 |
11.0 |
0.6 |
3 |
602.0 |
10.0 |
0.9 |
3 |
673.0 |
10.0 |
0.9 |
3 |
764.0 |
20.0 |
0.6 |
3 |
822.0 |
19.0 |
-0.9 |
3 |
891.0 |
7.0 |
-1.0 |
3 |
1180.0 |
6.5 |
1.6 |
3 |
1294.0 |
20.0 |
-0.4 |
3 |
1690.0 |
11.0 |
1.3 |
3 |
1920.0 |
9.0 |
1.7 |
3 |
2200.0 |
15.0 |
1.3 |
3 |
2680.0 |
3.0 |
-1.4 |
3 |
4620.0 |
3.8 |
-0.9 |
3 |
5630.0 |
9.0 |
0.7 |
3 |
7430.0 |
6.0 |
1.1 |
3 |
9650.0 |
4.2 |
1.3 |
3 |
11850.0 |
4.5 |
1.0 |
3 |
14100.0 |
3.3 |
2.0 |
Download
|
These EQ is designed by ASR member flipflop.
Graphic EQ 15 bands
|
Set preamp gain to: -0.7dB.
|
Type |
Freq |
Q |
Gain |
3 |
25.0 |
2.14 |
0.5 |
3 |
40.0 |
2.14 |
0.5 |
3 |
63.0 |
2.14 |
0.5 |
3 |
100.0 |
2.14 |
0.25 |
3 |
160.0 |
2.14 |
0.0 |
3 |
250.0 |
2.14 |
0.0 |
3 |
400.0 |
2.14 |
0.0 |
3 |
630.0 |
2.14 |
0.0 |
3 |
1000.0 |
2.14 |
0.0 |
3 |
1600.0 |
2.14 |
0.0 |
3 |
2500.0 |
2.14 |
-0.25 |
3 |
4000.0 |
2.14 |
-0.25 |
3 |
6300.0 |
2.14 |
0.0 |
3 |
10000.0 |
2.14 |
0.0 |
3 |
16000.0 |
2.14 |
0.5 |
Download
|
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
|
Set preamp gain to: -0.8dB.
|
Type |
Freq |
Q |
Gain |
3 |
20.0 |
4.32 |
0.0 |
3 |
25.0 |
4.32 |
0.5 |
3 |
31.0 |
4.32 |
0.5 |
3 |
40.0 |
4.32 |
0.5 |
3 |
50.0 |
4.32 |
0.5 |
3 |
63.0 |
4.32 |
0.5 |
3 |
80.0 |
4.32 |
0.5 |
3 |
100.0 |
4.32 |
0.25 |
3 |
125.0 |
4.32 |
0.0 |
3 |
160.0 |
4.32 |
0.0 |
3 |
200.0 |
4.32 |
0.0 |
3 |
250.0 |
4.32 |
0.0 |
3 |
315.0 |
4.32 |
0.0 |
3 |
400.0 |
4.32 |
0.0 |
3 |
500.0 |
4.32 |
0.0 |
3 |
630.0 |
4.32 |
0.0 |
3 |
800.0 |
4.32 |
0.0 |
3 |
1000.0 |
4.32 |
0.0 |
3 |
1250.0 |
4.32 |
0.0 |
3 |
1600.0 |
4.32 |
0.0 |
3 |
2000.0 |
4.32 |
0.25 |
3 |
2500.0 |
4.32 |
-0.25 |
3 |
3150.0 |
4.32 |
-0.25 |
3 |
4000.0 |
4.32 |
-0.25 |
3 |
5000.0 |
4.32 |
-0.25 |
3 |
6300.0 |
4.32 |
0.0 |
3 |
8000.0 |
4.32 |
0.0 |
3 |
10000.0 |
4.32 |
0.0 |
3 |
12000.0 |
4.32 |
0.0 |
3 |
16000.0 |
4.32 |
0.25 |
3 |
20000.0 |
4.32 |
0.0 |
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
