What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 164.8Hz (resp. 62.3Hz).
-
Reference level is normalised to -0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 4.3dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 70.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 2.89
and would be 5.5 with a
perfect subwoofer.
- Details:
NBD: ON 0.513,
LW 0.467, SP
0.434, PIR
0.417; SM:
SP0.583,
PIR0.152; LFQ
0.318, LFX 58Hz
- Tonality (Preference) Score is 5.88
with an EQ and would be 8.22 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.329,
LW 0.268, SP
0.362, PIR
0.277; SM:
SP0.95,
PIR0.944; LFQ 0.318, LFX 50Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
102.0 |
0.39 |
2.99 |
| 3 |
332.0 |
1.71 |
1.71 |
| 3 |
976.0 |
2.46 |
-5.11 |
| 3 |
1887.0 |
1.44 |
2.35 |
| 3 |
2862.0 |
2.27 |
-1.59 |
| 3 |
5165.0 |
2.22 |
-2.62 |
| 3 |
11476.0 |
2.82 |
-2.93 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -0.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
345.0 |
2.8 |
0.7 |
| 3 |
423.0 |
10.0 |
0.4 |
| 3 |
470.0 |
14.0 |
-0.5 |
| 3 |
568.0 |
2.387 |
-2.0 |
| 3 |
788.0 |
7.5 |
0.7 |
| 3 |
879.0 |
10.0 |
-0.8 |
| 3 |
998.0 |
1.779 |
-6.0 |
| 3 |
1040.0 |
9.0 |
0.6 |
| 3 |
1215.0 |
10.0 |
-0.8 |
| 3 |
1361.0 |
8.0 |
0.8 |
| 3 |
2015.0 |
10.0 |
0.4 |
| 3 |
2025.0 |
1.599 |
1.8 |
| 3 |
2912.0 |
1.504 |
-3.6 |
| 3 |
4894.0 |
2.301 |
-3.4 |
| 3 |
7873.0 |
2.327 |
-6.0 |
| 3 |
7892.0 |
4.9 |
5.1 |
| 3 |
9830.0 |
13.0 |
0.6 |
| 3 |
10800.0 |
8.0 |
-0.6 |
| 3 |
12140.0 |
11.0 |
0.6 |
| 3 |
12162.0 |
1.358 |
-4.3 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.75 |
| 3 |
40.0 |
2.14 |
0.75 |
| 3 |
63.0 |
2.14 |
0.75 |
| 3 |
100.0 |
2.14 |
0.75 |
| 3 |
160.0 |
2.14 |
0.75 |
| 3 |
250.0 |
2.14 |
0.75 |
| 3 |
400.0 |
2.14 |
0.5 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
-0.5 |
| 3 |
1600.0 |
2.14 |
0.0 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
-0.5 |
| 3 |
6300.0 |
2.14 |
-0.5 |
| 3 |
10000.0 |
2.14 |
-0.75 |
| 3 |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.75 |
| 3 |
31.0 |
4.32 |
0.75 |
| 3 |
40.0 |
4.32 |
0.75 |
| 3 |
50.0 |
4.32 |
0.75 |
| 3 |
63.0 |
4.32 |
0.75 |
| 3 |
80.0 |
4.32 |
0.75 |
| 3 |
100.0 |
4.32 |
0.75 |
| 3 |
125.0 |
4.32 |
0.75 |
| 3 |
160.0 |
4.32 |
0.75 |
| 3 |
200.0 |
4.32 |
0.75 |
| 3 |
250.0 |
4.32 |
0.75 |
| 3 |
315.0 |
4.32 |
0.5 |
| 3 |
400.0 |
4.32 |
0.5 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
-0.5 |
| 3 |
1000.0 |
4.32 |
-0.75 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
0.25 |
| 3 |
2000.0 |
4.32 |
0.5 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
-0.5 |
| 3 |
5000.0 |
4.32 |
-0.75 |
| 3 |
6300.0 |
4.32 |
-0.5 |
| 3 |
8000.0 |
4.32 |
-0.5 |
| 3 |
10000.0 |
4.32 |
-0.75 |
| 3 |
12000.0 |
4.32 |
-0.75 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
