What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 86.4dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
-
-3dB (resp. -6db) point v.s. reference is at 117.2Hz (resp. 85.0Hz).
-
Reference level is normalised to -0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.6dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.55
and would be 6.8 with a
perfect subwoofer.
- Details:
NBD: ON 0.438,
LW 0.438, SP
0.485, PIR
0.446; SM:
SP0.847,
PIR0.665; LFQ
0.74, LFX 82Hz
- Tonality (Preference) Score is 5.96
with an EQ and would be 8.1 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.304,
LW 0.299, SP
0.356, PIR
0.306; SM:
SP0.948,
PIR0.902; LFQ 0.492, LFX 45Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -6.5dB.
|
| Type |
Freq |
Q |
Gain |
| 5 |
117.0 |
0.54 |
2.96 |
| 3 |
117.0 |
0.27 |
2.98 |
| 3 |
117.0 |
0.27 |
2.68 |
| 3 |
158.0 |
1.17 |
-2.65 |
| 3 |
237.0 |
0.43 |
-2.99 |
| 3 |
965.0 |
2.7 |
-1.91 |
| 3 |
1822.0 |
0.8 |
0.93 |
| 3 |
2302.0 |
2.86 |
1.96 |
| 3 |
6276.0 |
1.26 |
0.97 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -1.9dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
303.0 |
1.8 |
0.6 |
| 3 |
369.0 |
6.0 |
-0.6 |
| 3 |
473.0 |
1.001 |
-1.0 |
| 3 |
553.0 |
12.0 |
-0.5 |
| 3 |
913.0 |
5.0 |
-2.0 |
| 3 |
1371.0 |
5.0 |
5.0 |
| 3 |
1403.0 |
2.249 |
-5.1 |
| 3 |
1695.0 |
4.998 |
2.3 |
| 3 |
1994.0 |
4.999 |
0.8 |
| 3 |
2065.0 |
18.0 |
0.7 |
| 3 |
2235.0 |
17.0 |
-1.1 |
| 3 |
2395.0 |
5.0 |
2.1 |
| 3 |
2410.0 |
14.0 |
1.2 |
| 3 |
2570.0 |
15.0 |
-1.1 |
| 3 |
3340.0 |
1.041 |
-1.1 |
| 3 |
3650.0 |
18.0 |
-0.6 |
| 3 |
5670.0 |
15.0 |
-0.6 |
| 3 |
5724.0 |
4.958 |
2.1 |
| 3 |
9771.0 |
1.265 |
-1.5 |
| 3 |
14394.0 |
5.0 |
1.2 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.75 |
| 3 |
40.0 |
2.14 |
0.75 |
| 3 |
63.0 |
2.14 |
0.75 |
| 3 |
100.0 |
2.14 |
0.75 |
| 3 |
160.0 |
2.14 |
0.25 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
0.5 |
| 3 |
2500.0 |
2.14 |
0.75 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
0.25 |
| 3 |
10000.0 |
2.14 |
0.0 |
| 3 |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.75 |
| 3 |
31.0 |
4.32 |
0.75 |
| 3 |
40.0 |
4.32 |
0.75 |
| 3 |
50.0 |
4.32 |
0.75 |
| 3 |
63.0 |
4.32 |
0.75 |
| 3 |
80.0 |
4.32 |
0.75 |
| 3 |
100.0 |
4.32 |
0.75 |
| 3 |
125.0 |
4.32 |
0.5 |
| 3 |
160.0 |
4.32 |
0.25 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.25 |
| 3 |
2000.0 |
4.32 |
0.75 |
| 3 |
2500.0 |
4.32 |
0.5 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.25 |
| 3 |
6300.0 |
4.32 |
0.25 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
0.0 |
| 3 |
12000.0 |
4.32 |
0.0 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
