What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 49.8Hz (resp. 41.0Hz).
-
Reference level is normalised to 0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.1dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.31
and would be 6.26 with a
perfect subwoofer.
- Details:
NBD: ON 0.355,
LW 0.3, SP
0.369, PIR
0.311; SM:
SP0.544,
PIR0.171; LFQ
0.414, LFX 41Hz
- Tonality (Preference) Score is 6.98
with an EQ and would be 8.47 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.297,
LW 0.212, SP
0.296, PIR
0.22; SM:
SP0.948,
PIR0.945; LFQ 0.526, LFX 32Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
64.0 |
0.99 |
2.99 |
| PK |
134.0 |
1.57 |
-0.51 |
| PK |
271.0 |
1.48 |
0.84 |
| PK |
366.0 |
0.67 |
0.55 |
| PK |
668.0 |
0.99 |
-0.66 |
| PK |
1948.0 |
1.77 |
2.51 |
| PK |
4492.0 |
2.05 |
-1.33 |
| PK |
6069.0 |
0.48 |
-2.28 |
| PK |
8478.0 |
0.37 |
-2.19 |
|
Download
|
This EQ optimise the Harman score and is a good start for far field listening like in your living room.
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -0.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
343.0 |
1.6 |
0.3 |
| PK |
377.0 |
14.0 |
-0.4 |
| PK |
406.0 |
9.0 |
1.0 |
| PK |
459.0 |
12.0 |
-0.7 |
| PK |
704.0 |
1.0 |
-1.3 |
| PK |
1609.0 |
4.78 |
-3.8 |
| PK |
1668.0 |
3.525 |
8.6 |
| PK |
1718.0 |
4.989 |
-3.8 |
| PK |
2220.0 |
20.0 |
1.0 |
| PK |
2750.0 |
4.0 |
-0.5 |
| PK |
3650.0 |
6.0 |
0.7 |
| PK |
3866.0 |
1.0 |
-3.2 |
| PK |
4450.0 |
5.0 |
-0.5 |
| PK |
6631.0 |
1.0 |
-3.0 |
| PK |
8450.0 |
9.0 |
-0.5 |
| PK |
10589.0 |
1.0 |
-2.8 |
| PK |
11565.0 |
5.0 |
1.1 |
| PK |
14900.0 |
5.0 |
-2.6 |
| PK |
16098.0 |
5.0 |
-2.6 |
| PK |
17304.0 |
5.0 |
-1.9 |
|
Download
|
This EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
-0.75 |
| PK |
6300.0 |
2.14 |
-0.75 |
| PK |
10000.0 |
2.14 |
-0.75 |
| PK |
16000.0 |
2.14 |
-0.75 |
|
Download
|
This EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.0 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
-0.25 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
-0.5 |
| PK |
4000.0 |
4.32 |
-0.75 |
| PK |
5000.0 |
4.32 |
-0.75 |
| PK |
6300.0 |
4.32 |
-0.75 |
| PK |
8000.0 |
4.32 |
-0.75 |
| PK |
10000.0 |
4.32 |
-0.75 |
| PK |
12000.0 |
4.32 |
-0.5 |
| PK |
16000.0 |
4.32 |
-0.75 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
This EQ is designed for a 31 bands graphical EQ.
EQ
Target v.s. EQ
Histogram of errors
Listening Window (fullrange)
Predicted In-Room Response (fullrange)
Comparison betweens various EQs
|
