What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 86.6dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 20.5Hz (resp. 165.5Hz).
-
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.9dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 0.09
and would be 4.51 with a
perfect subwoofer.
- Details:
NBD: ON 0.668,
LW 0.581, SP
0.518, PIR
0.507; SM:
SP0.241,
PIR0.006; LFQ
0.968, LFX 153Hz
- Tonality (Preference) Score is 4.28
with an EQ and would be 7.86 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.419,
LW 0.338, SP
0.291, PIR
0.257; SM:
SP0.159,
PIR0.859; LFQ 0.748, LFX 98Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
32.0 |
0.26 |
3.0 |
| PK |
95.0 |
1.87 |
2.99 |
| PK |
160.0 |
1.41 |
-4.52 |
| PK |
260.0 |
0.85 |
-3.2 |
| PK |
522.0 |
1.08 |
-5.71 |
| PK |
1288.0 |
1.21 |
-3.11 |
| PK |
1532.0 |
0.27 |
-2.65 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
AutomaticEQ LW (IIR)
|
|
Set preamp gain to: -8.9dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
56.0 |
0.26 |
2.98 |
| PK |
66.0 |
0.29 |
2.98 |
| PK |
78.0 |
0.29 |
3.0 |
| PK |
2545.0 |
1.14 |
2.27 |
| PK |
9372.0 |
0.32 |
1.76 |
| PK |
10713.0 |
2.55 |
2.13 |
| PK |
13537.0 |
1.18 |
2.85 |
|
Download
|
These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
|
AutomaticEQ Score (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
32.0 |
0.26 |
3.0 |
| PK |
95.0 |
1.87 |
2.99 |
| PK |
160.0 |
1.41 |
-4.52 |
| PK |
260.0 |
0.85 |
-3.2 |
| PK |
522.0 |
1.08 |
-5.71 |
| PK |
1288.0 |
1.21 |
-3.11 |
| PK |
1532.0 |
0.27 |
-2.65 |
|
Download
|
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -7.9dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
5.75 |
| PK |
40.0 |
2.14 |
6.0 |
| PK |
63.0 |
2.14 |
3.5 |
| PK |
100.0 |
2.14 |
1.25 |
| PK |
160.0 |
2.14 |
0.5 |
| PK |
250.0 |
2.14 |
0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.25 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -8.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
5.0 |
| PK |
31.0 |
4.32 |
6.0 |
| PK |
40.0 |
4.32 |
5.75 |
| PK |
50.0 |
4.32 |
4.75 |
| PK |
63.0 |
4.32 |
3.25 |
| PK |
80.0 |
4.32 |
1.75 |
| PK |
100.0 |
4.32 |
1.25 |
| PK |
125.0 |
4.32 |
0.75 |
| PK |
160.0 |
4.32 |
0.5 |
| PK |
200.0 |
4.32 |
0.25 |
| PK |
250.0 |
4.32 |
0.25 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
-0.25 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
-0.25 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
-0.25 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
-0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
