What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
Sensitivity: 86.7dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
-
-3dB (resp. -6db) point v.s. reference is at 200.0Hz (resp. 200.0Hz).
-
Reference level is normalised to 0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.9dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 1.9
and would be 6.81 with a
perfect subwoofer.
- Details:
NBD: ON 0.517,
LW 0.367, SP
0.389, PIR
0.318; SM:
SP0.676,
PIR0.593; LFQ
10.0, LFX 200Hz
- Tonality (Preference) Score is 3.6
with an EQ and would be 8.52 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.376,
LW 0.243, SP
0.255, PIR
0.142; SM:
SP0.863,
PIR0.948; LFQ 10.0, LFX 200Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
235.0 |
1.14 |
-4.34 |
| 3 |
910.0 |
3.0 |
-3.67 |
| 3 |
1161.0 |
3.0 |
2.99 |
| 3 |
1429.0 |
1.92 |
1.89 |
| 3 |
5347.0 |
1.05 |
-1.82 |
| 3 |
12301.0 |
1.67 |
0.69 |
| 3 |
16239.0 |
1.86 |
-1.2 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.0 |
| 3 |
40.0 |
2.14 |
0.0 |
| 3 |
63.0 |
2.14 |
0.0 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
-0.5 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
0.0 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
-0.25 |
| 3 |
6300.0 |
2.14 |
-0.25 |
| 3 |
10000.0 |
2.14 |
0.0 |
| 3 |
16000.0 |
2.14 |
-0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.9dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.0 |
| 3 |
31.0 |
4.32 |
0.0 |
| 3 |
40.0 |
4.32 |
0.0 |
| 3 |
50.0 |
4.32 |
0.0 |
| 3 |
63.0 |
4.32 |
0.0 |
| 3 |
80.0 |
4.32 |
0.0 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
-0.5 |
| 3 |
315.0 |
4.32 |
-0.25 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.25 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
0.0 |
| 3 |
1250.0 |
4.32 |
0.75 |
| 3 |
1600.0 |
4.32 |
0.5 |
| 3 |
2000.0 |
4.32 |
0.25 |
| 3 |
2500.0 |
4.32 |
0.25 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.0 |
| 3 |
6300.0 |
4.32 |
0.0 |
| 3 |
8000.0 |
4.32 |
0.0 |
| 3 |
10000.0 |
4.32 |
0.25 |
| 3 |
12000.0 |
4.32 |
0.25 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
