What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Sound and Recording.
-
Format of the data is
a scanned image
.
-
-3dB (resp. -6db) point v.s. reference is at 33.1Hz (resp. 31.1Hz).
-
Reference level is normalised to 0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.6dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.81
and would be 6.24 with a
perfect subwoofer.
- Details:
NBD: ON 0.67,
LW 0.608, SP
0.524, PIR
0.537; SM:
SP0.844,
PIR0.791; LFQ
1.718, LFX 31Hz
- Tonality (Preference) Score is 6.58
with an EQ and would be 7.78 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.406,
LW 0.374, SP
0.368, PIR
0.314; SM:
SP0.89,
PIR0.883; LFQ 1.718, LFX 27Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
28.0 |
1.36 |
3.0 |
| PK |
92.0 |
1.12 |
-3.63 |
| PK |
252.0 |
2.47 |
-1.12 |
| PK |
540.0 |
1.3 |
-3.41 |
| PK |
714.0 |
3.0 |
3.0 |
| PK |
2964.0 |
2.97 |
-3.62 |
| PK |
9001.0 |
1.76 |
-3.38 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
-0.25 |
| PK |
100.0 |
2.14 |
-0.5 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
-0.25 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
0.0 |
| PK |
10000.0 |
2.14 |
-0.25 |
| PK |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.0 |
| PK |
63.0 |
4.32 |
-0.25 |
| PK |
80.0 |
4.32 |
-0.5 |
| PK |
100.0 |
4.32 |
-0.5 |
| PK |
125.0 |
4.32 |
-0.5 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
-0.25 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
0.25 |
| PK |
1600.0 |
4.32 |
0.25 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
-0.25 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
0.25 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.5 |
| PK |
16000.0 |
4.32 |
0.75 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
