What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 56.4Hz (resp. 52.7Hz).
-
Reference level is normalised to -0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.0dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.56
and would be 5.97 with a
perfect subwoofer.
- Details:
NBD: ON 0.532,
LW 0.48, SP
0.427, PIR
0.445; SM:
SP0.731,
PIR0.409; LFQ
0.793, LFX 52Hz
- Tonality (Preference) Score is 5.64
with an EQ and would be 7.92 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.38,
LW 0.337, SP
0.345, PIR
0.31; SM:
SP0.962,
PIR0.911; LFQ 0.793, LFX 49Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
54.0 |
1.89 |
3.0 |
| 3 |
92.0 |
1.32 |
-3.84 |
| 3 |
332.0 |
0.4 |
0.8 |
| 3 |
666.0 |
2.97 |
-1.64 |
| 3 |
3405.0 |
2.74 |
3.0 |
| 3 |
5347.0 |
3.0 |
1.36 |
| 3 |
14633.0 |
0.65 |
-5.36 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
AutomaticEQ LW (IIR)
|
|
Set preamp gain to: -3.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
58.0 |
2.96 |
2.97 |
| 3 |
89.0 |
2.33 |
-2.47 |
| 3 |
113.0 |
1.34 |
-1.69 |
| 3 |
271.0 |
0.87 |
1.21 |
| 3 |
3438.0 |
2.99 |
2.91 |
| 3 |
5135.0 |
1.19 |
2.05 |
| 3 |
13997.0 |
0.81 |
-2.98 |
|
Download
|
These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
|
AutomaticEQ Score (IIR)
|
|
Set preamp gain to: -2.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
56.0 |
2.13 |
2.95 |
| 3 |
87.0 |
2.6 |
-2.75 |
| 3 |
109.0 |
1.55 |
-2.07 |
| 3 |
262.0 |
0.28 |
0.73 |
| 3 |
3325.0 |
1.83 |
2.83 |
| 3 |
13092.0 |
0.91 |
-2.3 |
| 3 |
14965.0 |
0.91 |
-2.58 |
|
Download
|
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -31.6dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
349.0 |
11.0 |
0.4 |
| 3 |
392.0 |
20.0 |
-1.1 |
| 3 |
540.0 |
21.0 |
1.1 |
| 3 |
653.0 |
4.0 |
-1.5 |
| 3 |
841.0 |
5.0 |
1.6 |
| 3 |
1041.0 |
2.997 |
-8.7 |
| 3 |
1042.0 |
5.0 |
10.8 |
| 3 |
1457.0 |
5.0 |
11.5 |
| 3 |
1484.0 |
5.0 |
-11.1 |
| 3 |
2256.0 |
1.001 |
3.2 |
| 3 |
2260.0 |
2.512 |
-1.7 |
| 3 |
3167.0 |
5.0 |
-0.8 |
| 3 |
3425.0 |
1.967 |
5.6 |
| 3 |
5488.0 |
1.923 |
5.0 |
| 3 |
7486.0 |
5.0 |
2.1 |
| 3 |
10047.0 |
1.01 |
9.8 |
| 3 |
11412.0 |
4.425 |
11.6 |
| 3 |
12338.0 |
1.001 |
12.0 |
| 3 |
13176.0 |
4.983 |
-1.3 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
-0.5 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.25 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
0.25 |
| 3 |
1600.0 |
2.14 |
0.0 |
| 3 |
2500.0 |
2.14 |
0.25 |
| 3 |
4000.0 |
2.14 |
0.5 |
| 3 |
6300.0 |
2.14 |
0.25 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
-0.25 |
| 3 |
100.0 |
4.32 |
-0.5 |
| 3 |
125.0 |
4.32 |
-0.25 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
0.25 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
0.25 |
| 3 |
3150.0 |
4.32 |
0.25 |
| 3 |
4000.0 |
4.32 |
0.25 |
| 3 |
5000.0 |
4.32 |
0.0 |
| 3 |
6300.0 |
4.32 |
0.0 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
-0.75 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
