What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
Sensitivity: 87.0dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 38.3Hz (resp. 32.7Hz).
-
Reference level is normalised to 0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.9dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.01
and would be 4.45 with a
perfect subwoofer.
- Details:
NBD: ON 0.677,
LW 0.613, SP
0.632, PIR
0.537; SM:
SP0.266,
PIR0.029; LFQ
0.912, LFX 31Hz
- Tonality (Preference) Score is 5.97
with an EQ and would be 7.14 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.593,
LW 0.5, SP
0.49, PIR
0.382; SM:
SP0.903,
PIR0.898; LFQ 0.912, LFX 27Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
31.0 |
0.32 |
3.0 |
| PK |
98.0 |
1.33 |
-5.21 |
| PK |
910.0 |
2.98 |
2.12 |
| PK |
2023.0 |
1.78 |
2.85 |
| PK |
2964.0 |
1.6 |
-3.07 |
| PK |
4495.0 |
2.84 |
-0.95 |
| PK |
13186.0 |
0.31 |
-5.79 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
-0.5 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.25 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.75 |
| PK |
16000.0 |
2.14 |
-0.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
-0.25 |
| PK |
80.0 |
4.32 |
-0.5 |
| PK |
100.0 |
4.32 |
-0.5 |
| PK |
125.0 |
4.32 |
-0.5 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
-0.75 |
| PK |
4000.0 |
4.32 |
-0.75 |
| PK |
5000.0 |
4.32 |
-0.75 |
| PK |
6300.0 |
4.32 |
-0.75 |
| PK |
8000.0 |
4.32 |
-0.75 |
| PK |
10000.0 |
4.32 |
-0.75 |
| PK |
12000.0 |
4.32 |
-1.0 |
| PK |
16000.0 |
4.32 |
-0.75 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
