What we know about the measurement:
- Quality of the measurement data is
unknown.
-
Origin of the data is Paradigm.
-
Format of the data is
a scanned image
.
-
Sensitivity: 87.5dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 40.8Hz (resp. 40.5Hz).
-
Reference level is normalised to 0.8dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.2dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.31
and would be 6.23 with a
perfect subwoofer.
- Details:
NBD: ON 0.411,
LW 0.342, SP
0.342, PIR
0.327; SM:
SP0.612,
PIR0.239; LFQ
1.4, LFX 40Hz
- Tonality (Preference) Score is 6.87
with an EQ and would be 8.79 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.26,
LW 0.175, SP
0.196, PIR
0.129; SM:
SP0.943,
PIR0.926; LFQ 1.4, LFX 40Hz
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
71.0 |
1.29 |
-2.75 |
| PK |
106.0 |
2.07 |
-1.28 |
| PK |
148.0 |
0.3 |
0.35 |
| PK |
873.0 |
2.67 |
-2.08 |
| PK |
1220.0 |
2.23 |
-2.11 |
| PK |
1884.0 |
0.44 |
1.32 |
| PK |
4803.0 |
1.97 |
2.03 |
| PK |
11077.0 |
2.1 |
-2.83 |
| PK |
15474.0 |
0.83 |
-2.75 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.0 |
| PK |
40.0 |
2.14 |
0.0 |
| PK |
63.0 |
2.14 |
-0.5 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
0.25 |
| PK |
6300.0 |
2.14 |
0.0 |
| PK |
10000.0 |
2.14 |
-0.5 |
| PK |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.0 |
| PK |
31.0 |
4.32 |
0.0 |
| PK |
40.0 |
4.32 |
0.0 |
| PK |
50.0 |
4.32 |
-0.25 |
| PK |
63.0 |
4.32 |
-0.5 |
| PK |
80.0 |
4.32 |
-0.25 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
0.25 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
-0.5 |
| PK |
12000.0 |
4.32 |
-0.5 |
| PK |
16000.0 |
4.32 |
-0.5 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
