What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Onesystems.
-
Format of the data is
a GLL file
.
-
Sensitivity:
-
Sensitivity: 103.7dB (avg. 100Hz-1kHz for 2.83V estimated at 1m).
-
Sensitivity: 83.7dB computed at the measurement distance (10.0m) over the same frequency range.
-
-3dB (resp. -6db) point v.s. reference is at 73.0Hz (resp. 63.0Hz).
-
Reference level is normalised to -0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.8dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.24
and would be 6.05 with a
perfect subwoofer.
- Details:
NBD: ON 0.621,
LW 0.497, SP
0.543, PIR
0.494; SM:
SP0.723,
PIR0.601; LFQ
2.719, LFX 64Hz
- Tonality (Preference) Score is 5.99
with an EQ and would be 8.05 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.418,
LW 0.267, SP
0.358, PIR
0.253; SM:
SP0.944,
PIR0.936; LFQ 2.363, LFX 43Hz
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
89.0 |
1.06 |
2.97 |
| PK |
229.0 |
0.45 |
-2.99 |
| PK |
366.0 |
2.15 |
2.97 |
| PK |
965.0 |
0.48 |
1.79 |
| PK |
1704.0 |
2.91 |
-2.9 |
| PK |
2082.0 |
2.98 |
2.93 |
| PK |
3555.0 |
0.94 |
-2.96 |
| PK |
7669.0 |
2.97 |
-2.67 |
| PK |
12246.0 |
1.0 |
-2.74 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.5 |
| PK |
630.0 |
2.14 |
0.5 |
| PK |
1000.0 |
2.14 |
0.5 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.5 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
0.25 |
| PK |
10000.0 |
2.14 |
0.25 |
| PK |
16000.0 |
2.14 |
1.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.25 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.25 |
| PK |
400.0 |
4.32 |
0.5 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.5 |
| PK |
800.0 |
4.32 |
0.25 |
| PK |
1000.0 |
4.32 |
0.5 |
| PK |
1250.0 |
4.32 |
0.5 |
| PK |
1600.0 |
4.32 |
0.25 |
| PK |
2000.0 |
4.32 |
0.5 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
1.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
