What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Onesystems.
-
Format of the data is
a GLL file
.
-
Sensitivity:
-
Sensitivity: 90.6dB (avg. 100Hz-1kHz for 2.83V estimated at 1m).
-
Sensitivity: 70.6dB computed at the measurement distance (10.0m) over the same frequency range.
-
-3dB (resp. -6db) point v.s. reference is at 118.0Hz (resp. 71.0Hz).
-
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.0dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.49
and would be 6.36 with a
perfect subwoofer.
- Details:
NBD: ON 0.46,
LW 0.485, SP
0.608, PIR
0.544; SM:
SP0.797,
PIR0.625; LFQ
1.265, LFX 67Hz
- Tonality (Preference) Score is 5.64
with an EQ and would be 7.96 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.261,
LW 0.248, SP
0.386, PIR
0.318; SM:
SP0.902,
PIR0.81; LFQ 1.265, LFX 49Hz
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -4.8dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
118.0 |
0.63 |
2.98 |
| PK |
118.0 |
0.82 |
1.9 |
| PK |
143.0 |
2.48 |
-2.97 |
| PK |
280.0 |
1.75 |
-2.88 |
| PK |
478.0 |
2.72 |
-1.65 |
| PK |
1394.0 |
2.99 |
-1.75 |
| PK |
2082.0 |
2.15 |
2.13 |
| PK |
11454.0 |
2.8 |
2.92 |
| LS |
12246.0 |
0.47 |
1.38 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.75 |
| PK |
40.0 |
2.14 |
0.75 |
| PK |
63.0 |
2.14 |
0.75 |
| PK |
100.0 |
2.14 |
0.75 |
| PK |
160.0 |
2.14 |
0.25 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.5 |
| PK |
1000.0 |
2.14 |
0.25 |
| PK |
1600.0 |
2.14 |
0.5 |
| PK |
2500.0 |
2.14 |
0.5 |
| PK |
4000.0 |
2.14 |
0.25 |
| PK |
6300.0 |
2.14 |
0.0 |
| PK |
10000.0 |
2.14 |
0.5 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.75 |
| PK |
31.0 |
4.32 |
0.75 |
| PK |
40.0 |
4.32 |
0.75 |
| PK |
50.0 |
4.32 |
0.75 |
| PK |
63.0 |
4.32 |
0.75 |
| PK |
80.0 |
4.32 |
0.75 |
| PK |
100.0 |
4.32 |
0.75 |
| PK |
125.0 |
4.32 |
0.5 |
| PK |
160.0 |
4.32 |
0.25 |
| PK |
200.0 |
4.32 |
0.25 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
-0.25 |
| PK |
630.0 |
4.32 |
0.5 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.25 |
| PK |
1250.0 |
4.32 |
0.25 |
| PK |
1600.0 |
4.32 |
0.5 |
| PK |
2000.0 |
4.32 |
0.75 |
| PK |
2500.0 |
4.32 |
0.5 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
0.25 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.25 |
| PK |
10000.0 |
4.32 |
0.5 |
| PK |
12000.0 |
4.32 |
0.5 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
