What we know about the measurement:
- Quality of the measurement data is
unknown.
-
Origin of the data is Novacoustic.
-
Format of the data is
a GLL file
.
-
-3dB (resp. -6db) point v.s. reference is at 90.0Hz (resp. 85.0Hz).
-
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 10.5dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 0.16
and would be 3.42 with a
perfect subwoofer.
- Details:
NBD: ON 1.305,
LW 0.963, SP
0.956, PIR
0.895; SM:
SP0.842,
PIR0.717; LFQ
1.507, LFX 82Hz
- Tonality (Preference) Score is 1.74
with an EQ and would be 4.93 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 1.008,
LW 0.745, SP
0.843, PIR
0.731; SM:
SP0.923,
PIR0.842; LFQ 1.507, LFX 79Hz
-
Vendor specifications:
- Dispersion: 90° horizontal and 90° vertical.
- Sensitivity 98 dB
- Impedance 8 Ohm
- SPL
- Size
- Width 360mm
- Height 360mm
- Depth 360mm
- Weight 18.5kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
90.0 |
0.7 |
2.73 |
| PK |
529.0 |
0.32 |
-1.64 |
| PK |
790.0 |
2.91 |
1.89 |
| PK |
1304.0 |
2.96 |
2.96 |
| PK |
1648.0 |
2.92 |
2.8 |
| PK |
4345.0 |
3.0 |
-2.46 |
| PK |
6069.0 |
2.91 |
2.92 |
| PK |
9691.0 |
2.65 |
-2.83 |
| PK |
16000.0 |
0.97 |
-0.51 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.9dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.25 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
-0.25 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
0.25 |
| PK |
1600.0 |
2.14 |
0.75 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
0.25 |
| PK |
6300.0 |
2.14 |
0.75 |
| PK |
10000.0 |
2.14 |
0.25 |
| PK |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.5 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.5 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
0.25 |
| PK |
1000.0 |
4.32 |
0.25 |
| PK |
1250.0 |
4.32 |
1.0 |
| PK |
1600.0 |
4.32 |
0.75 |
| PK |
2000.0 |
4.32 |
0.25 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.5 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
0.5 |
| PK |
6300.0 |
4.32 |
1.0 |
| PK |
8000.0 |
4.32 |
0.5 |
| PK |
10000.0 |
4.32 |
0.25 |
| PK |
12000.0 |
4.32 |
0.5 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
