What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 85.7Hz (resp. 69.6Hz).
-
Reference level is normalised to -0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 70.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 2.75
and would be 5.68 with a
perfect subwoofer.
- Details:
NBD: ON 0.6,
LW 0.515, SP
0.442, PIR
0.422; SM:
SP0.675,
PIR0.328; LFQ
0.244, LFX 69Hz
- Tonality (Preference) Score is 5.33
with an EQ and would be 8.12 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.375,
LW 0.311, SP
0.295, PIR
0.259; SM:
SP0.952,
PIR0.928; LFQ 0.204, LFX 64Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
148.0 |
1.3 |
-2.98 |
| 3 |
447.0 |
1.07 |
1.46 |
| 3 |
691.0 |
2.89 |
-1.48 |
| 3 |
844.0 |
2.87 |
1.65 |
| 3 |
1067.0 |
2.43 |
-2.96 |
| 3 |
2631.0 |
0.99 |
-2.66 |
| 3 |
7173.0 |
1.07 |
-1.9 |
| 3 |
11843.0 |
0.49 |
-1.79 |
| 5 |
13997.0 |
0.85 |
2.05 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -0.5dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
400.0 |
3.5 |
0.8 |
| 3 |
462.0 |
6.0 |
0.5 |
| 3 |
524.0 |
10.0 |
0.9 |
| 3 |
578.0 |
10.0 |
1.1 |
| 3 |
614.0 |
10.0 |
-0.9 |
| 3 |
901.0 |
5.0 |
12.0 |
| 3 |
920.0 |
5.0 |
-11.5 |
| 3 |
975.0 |
1.0 |
-2.1 |
| 3 |
1189.0 |
5.0 |
-0.8 |
| 3 |
2825.0 |
1.0 |
-3.9 |
| 3 |
2885.0 |
12.0 |
-0.6 |
| 3 |
3550.0 |
2.5 |
0.3 |
| 3 |
4670.0 |
6.0 |
-1.5 |
| 3 |
5450.0 |
5.2 |
-2.3 |
| 3 |
6680.0 |
12.0 |
0.5 |
| 3 |
8434.0 |
5.0 |
7.9 |
| 3 |
8515.0 |
2.307 |
-10.4 |
| 3 |
11831.0 |
5.0 |
-2.0 |
| 3 |
14614.0 |
1.931 |
-4.4 |
| 3 |
16846.0 |
5.0 |
-1.6 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
-0.25 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.25 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
-0.5 |
| 3 |
1600.0 |
2.14 |
-0.25 |
| 3 |
2500.0 |
2.14 |
-0.5 |
| 3 |
4000.0 |
2.14 |
-0.5 |
| 3 |
6300.0 |
2.14 |
-0.75 |
| 3 |
10000.0 |
2.14 |
-0.75 |
| 3 |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.5 |
| 3 |
31.0 |
4.32 |
0.5 |
| 3 |
40.0 |
4.32 |
0.5 |
| 3 |
50.0 |
4.32 |
0.5 |
| 3 |
63.0 |
4.32 |
0.5 |
| 3 |
80.0 |
4.32 |
0.5 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
-0.25 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.25 |
| 3 |
315.0 |
4.32 |
0.5 |
| 3 |
400.0 |
4.32 |
0.5 |
| 3 |
500.0 |
4.32 |
0.5 |
| 3 |
630.0 |
4.32 |
0.25 |
| 3 |
800.0 |
4.32 |
0.25 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
-0.25 |
| 3 |
2500.0 |
4.32 |
-0.5 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.0 |
| 3 |
6300.0 |
4.32 |
0.0 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
-0.25 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
