What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 86.9dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 54.2Hz (resp. 43.9Hz).
-
Reference level is normalised to 0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.66
and would be 6.54 with a
perfect subwoofer.
- Details:
NBD: ON 0.484,
LW 0.407, SP
0.461, PIR
0.414; SM:
SP0.776,
PIR0.563; LFQ
0.737, LFX 39Hz
- Tonality (Preference) Score is 7.08
with an EQ and would be 7.97 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.427,
LW 0.315, SP
0.356, PIR
0.289; SM:
SP0.973,
PIR0.959; LFQ 0.733, LFX 23Hz
- Link to Original review.
AutomaticEQ (IIR)
|
Set preamp gain to: -2.2dB.
|
Type |
Freq |
Q |
Gain |
HS |
62.0 |
0.7 |
-2.95 |
PK |
121.0 |
0.88 |
-2.98 |
PK |
194.0 |
1.26 |
2.4 |
PK |
447.0 |
2.59 |
2.66 |
PK |
1648.0 |
1.2 |
2.66 |
PK |
3438.0 |
2.24 |
-2.14 |
PK |
5310.0 |
1.42 |
-2.64 |
PK |
7417.0 |
1.78 |
1.0 |
LS |
14965.0 |
0.8 |
2.25 |
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
Graphic EQ 15 bands
|
Set preamp gain to: -0.3dB.
|
Type |
Freq |
Q |
Gain |
PK |
25.0 |
2.14 |
0.25 |
PK |
40.0 |
2.14 |
0.25 |
PK |
63.0 |
2.14 |
0.0 |
PK |
100.0 |
2.14 |
-0.5 |
PK |
160.0 |
2.14 |
0.0 |
PK |
250.0 |
2.14 |
0.0 |
PK |
400.0 |
2.14 |
0.25 |
PK |
630.0 |
2.14 |
0.0 |
PK |
1000.0 |
2.14 |
0.0 |
PK |
1600.0 |
2.14 |
0.25 |
PK |
2500.0 |
2.14 |
0.0 |
PK |
4000.0 |
2.14 |
-0.25 |
PK |
6300.0 |
2.14 |
-0.25 |
PK |
10000.0 |
2.14 |
0.0 |
PK |
16000.0 |
2.14 |
0.0 |
Download
|
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
|
Set preamp gain to: -0.4dB.
|
Type |
Freq |
Q |
Gain |
PK |
20.0 |
4.32 |
0.0 |
PK |
25.0 |
4.32 |
0.25 |
PK |
31.0 |
4.32 |
0.25 |
PK |
40.0 |
4.32 |
0.25 |
PK |
50.0 |
4.32 |
0.25 |
PK |
63.0 |
4.32 |
0.0 |
PK |
80.0 |
4.32 |
-0.25 |
PK |
100.0 |
4.32 |
-0.5 |
PK |
125.0 |
4.32 |
-0.25 |
PK |
160.0 |
4.32 |
0.0 |
PK |
200.0 |
4.32 |
0.0 |
PK |
250.0 |
4.32 |
0.0 |
PK |
315.0 |
4.32 |
0.0 |
PK |
400.0 |
4.32 |
0.25 |
PK |
500.0 |
4.32 |
0.25 |
PK |
630.0 |
4.32 |
0.0 |
PK |
800.0 |
4.32 |
0.0 |
PK |
1000.0 |
4.32 |
0.0 |
PK |
1250.0 |
4.32 |
0.0 |
PK |
1600.0 |
4.32 |
0.25 |
PK |
2000.0 |
4.32 |
0.0 |
PK |
2500.0 |
4.32 |
0.0 |
PK |
3150.0 |
4.32 |
-0.25 |
PK |
4000.0 |
4.32 |
-0.25 |
PK |
5000.0 |
4.32 |
-0.25 |
PK |
6300.0 |
4.32 |
0.0 |
PK |
8000.0 |
4.32 |
0.0 |
PK |
10000.0 |
4.32 |
0.0 |
PK |
12000.0 |
4.32 |
0.0 |
PK |
16000.0 |
4.32 |
0.0 |
PK |
20000.0 |
4.32 |
0.0 |
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
