What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
Sensitivity: 86.1dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 276.8Hz (resp. 249.5Hz).
-
Reference level is normalised to 0.6dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 5.6dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is -1.23
and would be 4.09 with a
perfect subwoofer.
- Details:
NBD: ON 0.83,
LW 0.73, SP
0.655, PIR
0.692; SM:
SP0.006,
PIR0.238; LFQ
10.0, LFX 249Hz
- Tonality (Preference) Score is -0.07
with an EQ and would be 5.25 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.708,
LW 0.568, SP
0.517, PIR
0.532; SM:
SP0.036,
PIR0.398; LFQ 10.0, LFX 249Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
235.0 |
2.82 |
2.29 |
| PK |
395.0 |
1.3 |
2.16 |
| PK |
643.0 |
2.99 |
-1.11 |
| PK |
2964.0 |
0.92 |
-2.97 |
| PK |
4989.0 |
1.33 |
3.0 |
| PK |
11882.0 |
1.03 |
-7.46 |
| PK |
15685.0 |
0.87 |
-8.96 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
AutomaticEQ LW (IIR)
|
|
Set preamp gain to: -2.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
276.0 |
0.5 |
-0.75 |
| PK |
276.0 |
0.51 |
1.62 |
| PK |
276.0 |
0.32 |
-1.91 |
| PK |
276.0 |
1.77 |
2.18 |
| PK |
418.0 |
1.21 |
2.3 |
| PK |
3438.0 |
2.94 |
-2.9 |
| PK |
5135.0 |
1.99 |
2.84 |
|
Download
|
These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
|
AutomaticEQ Score (IIR)
|
|
Set preamp gain to: -5.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
276.0 |
0.79 |
2.34 |
| PK |
276.0 |
2.25 |
-2.22 |
| PK |
276.0 |
1.12 |
1.82 |
| PK |
965.0 |
0.47 |
-0.57 |
| PK |
2909.0 |
1.47 |
-1.76 |
| PK |
4645.0 |
1.84 |
2.99 |
| PK |
5677.0 |
1.18 |
2.99 |
|
Download
|
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.0 |
| PK |
40.0 |
2.14 |
0.0 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.25 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
0.25 |
| PK |
10000.0 |
2.14 |
-0.75 |
| PK |
16000.0 |
2.14 |
-1.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.0 |
| PK |
31.0 |
4.32 |
0.0 |
| PK |
40.0 |
4.32 |
0.0 |
| PK |
50.0 |
4.32 |
0.0 |
| PK |
63.0 |
4.32 |
0.0 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.25 |
| PK |
400.0 |
4.32 |
0.25 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
-0.25 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
-0.25 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
0.25 |
| PK |
6300.0 |
4.32 |
0.25 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
-0.75 |
| PK |
12000.0 |
4.32 |
-1.0 |
| PK |
16000.0 |
4.32 |
-1.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
