What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 98.1Hz (resp. 71.8Hz).
-
Reference level is normalised to -0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.3dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.37
and would be 6.36 with a
perfect subwoofer.
- Details:
NBD: ON 0.354,
LW 0.357, SP
0.424, PIR
0.35; SM:
SP0.59,
PIR0.263; LFQ
1.264, LFX 71Hz
- Tonality (Preference) Score is 5.95
with an EQ and would be 8.31 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.328,
LW 0.262, SP
0.356, PIR
0.246; SM:
SP0.914,
PIR0.942; LFQ 1.083, LFX 51Hz
- Link to Original review.
-
Vendor specifications:
- Sensitivity 92 dB
- Impedance 4 Ohm
- Size
- Width 266mm
- Height 318mm
- Depth 308mm
- Weight 11.5kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -5.1dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
98.0 |
0.86 |
2.93 |
| PK |
98.0 |
0.27 |
2.97 |
| PK |
117.0 |
1.44 |
-1.57 |
| PK |
478.0 |
2.53 |
2.37 |
| PK |
604.0 |
1.26 |
-2.94 |
| PK |
1762.0 |
0.79 |
2.25 |
| PK |
3930.0 |
1.64 |
-0.93 |
| PK |
7930.0 |
1.43 |
-2.49 |
| PK |
15474.0 |
0.93 |
-1.32 |
|
Download
|
This EQ optimise the Harman score and is a good start for far field listening like in your living room.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.5 |
| PK |
160.0 |
2.14 |
0.25 |
| PK |
250.0 |
2.14 |
0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
-0.5 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.5 |
| PK |
16000.0 |
2.14 |
-0.5 |
|
Download
|
This EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.75 |
| PK |
31.0 |
4.32 |
0.75 |
| PK |
40.0 |
4.32 |
0.75 |
| PK |
50.0 |
4.32 |
0.75 |
| PK |
63.0 |
4.32 |
0.75 |
| PK |
80.0 |
4.32 |
0.75 |
| PK |
100.0 |
4.32 |
0.5 |
| PK |
125.0 |
4.32 |
0.5 |
| PK |
160.0 |
4.32 |
0.5 |
| PK |
200.0 |
4.32 |
0.25 |
| PK |
250.0 |
4.32 |
0.25 |
| PK |
315.0 |
4.32 |
0.25 |
| PK |
400.0 |
4.32 |
0.25 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
-0.5 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.5 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
-0.5 |
| PK |
10000.0 |
4.32 |
-0.75 |
| PK |
12000.0 |
4.32 |
-0.5 |
| PK |
16000.0 |
4.32 |
-0.75 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
This EQ is designed for a 31 bands graphical EQ.
EQ
Target v.s. EQ
Histogram of errors
Listening Window (fullrange)
Predicted In-Room Response (fullrange)
Comparison betweens various EQs
|
