What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 85.3dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 101.1Hz (resp. 85.0Hz).
-
Reference level is normalised to 0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.8dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 2.21
and would be 5.38 with a
perfect subwoofer.
- Details:
NBD: ON 0.64,
LW 0.483, SP
0.479, PIR
0.398; SM:
SP0.577,
PIR0.21; LFQ
0.484, LFX 79Hz
- Tonality (Preference) Score is 5.18
with an EQ and would be 7.64 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.53,
LW 0.372, SP
0.397, PIR
0.3; SM:
SP0.934,
PIR0.941; LFQ 0.405, LFX 54Hz
- Vertical measurement
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -5.9dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
101.0 |
0.52 |
2.98 |
| PK |
125.0 |
1.68 |
-2.88 |
| PK |
245.0 |
1.64 |
0.9 |
| PK |
447.0 |
1.23 |
1.18 |
| PK |
1304.0 |
1.13 |
-2.43 |
| PK |
2545.0 |
0.33 |
-2.35 |
| LS |
2631.0 |
1.14 |
2.99 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
0.25 |
| PK |
160.0 |
2.14 |
0.25 |
| PK |
250.0 |
2.14 |
0.5 |
| PK |
400.0 |
2.14 |
0.5 |
| PK |
630.0 |
2.14 |
0.25 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
-0.5 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
-0.5 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.25 |
| PK |
16000.0 |
2.14 |
-0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
0.25 |
| PK |
100.0 |
4.32 |
0.25 |
| PK |
125.0 |
4.32 |
0.25 |
| PK |
160.0 |
4.32 |
0.25 |
| PK |
200.0 |
4.32 |
0.5 |
| PK |
250.0 |
4.32 |
0.5 |
| PK |
315.0 |
4.32 |
0.5 |
| PK |
400.0 |
4.32 |
0.5 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.5 |
| PK |
1600.0 |
4.32 |
-0.5 |
| PK |
2000.0 |
4.32 |
-0.5 |
| PK |
2500.0 |
4.32 |
-0.5 |
| PK |
3150.0 |
4.32 |
-0.5 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
