What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is Kling Freitag.
-
Format of the data is
a GLL file
.
-
-3dB (resp. -6db) point v.s. reference is at 53.0Hz (resp. 51.5Hz).
-
Reference level is normalised to -8.6dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 10.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-40.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for toursound speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is 1.55
and would be 3.92 with a
perfect subwoofer.
- Details:
NBD: ON 1.237,
LW 1.035, SP
0.926, PIR
0.892; SM:
SP0.876,
PIR0.858; LFQ
4.86, LFX 51Hz
- Tonality (Preference) Score is 2.64
with an EQ and would be 5.12 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.965,
LW 0.726, SP
0.755, PIR
0.653; SM:
SP0.856,
PIR0.774; LFQ 4.86, LFX 54Hz
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -13.1dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
64.0 |
0.48 |
2.98 |
| PK |
187.0 |
1.64 |
-2.99 |
| PK |
447.0 |
2.45 |
2.99 |
| PK |
625.0 |
2.37 |
2.98 |
| PK |
2380.0 |
0.25 |
3.0 |
| PK |
3008.0 |
2.97 |
2.96 |
| PK |
3555.0 |
0.26 |
2.97 |
| PK |
5310.0 |
0.25 |
2.99 |
| PK |
10361.0 |
0.26 |
2.91 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -2.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
-0.5 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
0.5 |
| PK |
630.0 |
2.14 |
0.75 |
| PK |
1000.0 |
2.14 |
0.75 |
| PK |
1600.0 |
2.14 |
1.0 |
| PK |
2500.0 |
2.14 |
1.25 |
| PK |
4000.0 |
2.14 |
1.75 |
| PK |
6300.0 |
2.14 |
1.75 |
| PK |
10000.0 |
2.14 |
1.0 |
| PK |
16000.0 |
2.14 |
1.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.0 |
| PK |
80.0 |
4.32 |
-0.5 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
-0.5 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.5 |
| PK |
500.0 |
4.32 |
0.75 |
| PK |
630.0 |
4.32 |
0.75 |
| PK |
800.0 |
4.32 |
0.5 |
| PK |
1000.0 |
4.32 |
0.75 |
| PK |
1250.0 |
4.32 |
1.0 |
| PK |
1600.0 |
4.32 |
1.0 |
| PK |
2000.0 |
4.32 |
1.25 |
| PK |
2500.0 |
4.32 |
1.25 |
| PK |
3150.0 |
4.32 |
1.75 |
| PK |
4000.0 |
4.32 |
1.75 |
| PK |
5000.0 |
4.32 |
2.0 |
| PK |
6300.0 |
4.32 |
1.75 |
| PK |
8000.0 |
4.32 |
2.0 |
| PK |
10000.0 |
4.32 |
1.0 |
| PK |
12000.0 |
4.32 |
1.25 |
| PK |
16000.0 |
4.32 |
1.75 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
