What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
-3dB (resp. -6db) point v.s. reference is at 201.4Hz (resp. 201.4Hz).
-
Reference level is normalised to 0.8dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.2dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 1.01
and would be 5.95 with a
perfect subwoofer.
- Details:
NBD: ON 0.528,
LW 0.493, SP
0.637, PIR
0.491; SM:
SP0.691,
PIR0.456; LFQ
10.0, LFX 202Hz
- Tonality (Preference) Score is 1.25
with an EQ and would be 6.19 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.461,
LW 0.41, SP
0.589, PIR
0.396; SM:
SP0.672,
PIR0.363; LFQ 10.0, LFX 202Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -1.5dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
202.0 |
0.6 |
0.52 |
| PK |
354.0 |
2.9 |
1.94 |
| PK |
529.0 |
0.26 |
-2.21 |
| PK |
790.0 |
3.0 |
2.88 |
| PK |
1442.0 |
1.94 |
1.65 |
| PK |
2545.0 |
2.96 |
2.28 |
| PK |
2909.0 |
2.95 |
-1.68 |
| PK |
4492.0 |
0.47 |
1.11 |
| PK |
16000.0 |
1.28 |
-1.22 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.0 |
| PK |
40.0 |
2.14 |
0.0 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.25 |
| PK |
1600.0 |
2.14 |
0.5 |
| PK |
2500.0 |
2.14 |
0.5 |
| PK |
4000.0 |
2.14 |
0.25 |
| PK |
6300.0 |
2.14 |
0.25 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.0 |
| PK |
31.0 |
4.32 |
0.0 |
| PK |
40.0 |
4.32 |
0.0 |
| PK |
50.0 |
4.32 |
0.0 |
| PK |
63.0 |
4.32 |
0.0 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.5 |
| PK |
1000.0 |
4.32 |
0.25 |
| PK |
1250.0 |
4.32 |
0.25 |
| PK |
1600.0 |
4.32 |
0.25 |
| PK |
2000.0 |
4.32 |
0.25 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
0.25 |
| PK |
6300.0 |
4.32 |
0.25 |
| PK |
8000.0 |
4.32 |
0.25 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
-0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
