What we know about the measurement:
Quality of the measurement data is
high .
Origin of the data is ASR.
Format of the data is
generated by a Klippel NFS
.
-3dB (resp. -6db) point v.s. reference is at 60.1Hz (resp. 54.2Hz).
Reference level is normalised to 0.4dB
computed over the frequency range [300.0Hz,
5000.0Hz].
Frequency deviation is 6.5dB over the same frequency range.
Directivity
Horizontal directivity
is (-40.0°, 40.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Vertical directivity
is (-30.0°, 30.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Tonality (Preference) Score
Tonality (Preference) Score is 2.71
and would be 5.22 with a
perfect subwoofer.
Details:
NBD: ON 0.572,
LW 0.546, SP
0.504, PIR
0.491; SM:
SP0.589,
PIR0.189; LFQ
0.688, LFX 55Hz
Tonality (Preference) Score is 5.34
with an EQ and would be 7.71 with a
perfect subwoofer and the same EQ.
Details:
NBD: ON 0.429,
LW 0.403, SP
0.367, PIR
0.339; SM:
SP0.954,
PIR0.911; LFQ 0.688, LFX 51Hz
Link to Original review .
AutomaticEQ (IIR)
Set preamp gain to: -2.7dB .
Type
Freq
Q
Gain
PK
40.0
0.63
2.95
PK
77.0
2.18
-2.93
PK
454.0
2.09
-0.74
PK
1083.0
3.0
2.95
PK
2168.0
3.0
2.96
PK
10341.0
0.26
-5.35
PK
11085.0
1.39
2.96
Download
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
maiky76@ASR LW (IIR)
Set preamp gain to: -0.0dB .
Type
Freq
Q
Gain
PK
585.0
5.4
-0.67
PK
4277.0
5.49
-0.5
PK
5057.0
2.82
-2.25
PK
7360.0
1.66
-2.06
PK
17029.0
3.43
-2.94
Download
These EQ is designed by ASR member maiky76. These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
maiky76@ASR (IIR)
Set preamp gain to: -0.0dB .
Type
Freq
Q
Gain
PK
584.0
7.93
-1.0
PK
2969.0
8.18
-0.74
PK
4810.0
2.07
-3.34
PK
7466.0
1.4
-3.06
PK
15783.0
2.44
-3.37
Download
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
flipflop@ASR (IIR)
Set preamp gain to: -3.1dB .
Type
Freq
Q
Gain
PK
606.0
6.0
-1.6
PK
652.0
15.0
2.7
PK
742.0
12.0
0.9
PK
871.0
5.5
-1.0
PK
987.0
13.0
-2.0
PK
1080.0
3.0
2.4
PK
1380.0
3.2
-1.9
PK
1570.0
14.0
1.2
PK
1725.0
15.0
-0.5
PK
1900.0
16.0
1.4
PK
2215.0
12.0
3.7
PK
2475.0
11.0
-2.0
PK
2990.0
8.0
-1.2
PK
4290.0
10.0
-0.8
PK
4910.0
2.3
-3.0
PK
7170.0
1.6
-2.9
PK
9650.0
3.0
-1.0
PK
12900.0
2.3
-1.3
PK
16050.0
3.5
-1.2
HS
19000.0
1.5772935127949521
-15.0
Download
These EQ is designed by ASR member flipflop.
Graphic EQ 15 bands
Set preamp gain to: -0.0dB .
Type
Freq
Q
Gain
PK
25.0
2.14
0.0
PK
40.0
2.14
0.0
PK
63.0
2.14
0.0
PK
100.0
2.14
0.0
PK
160.0
2.14
0.0
PK
250.0
2.14
0.0
PK
400.0
2.14
-0.25
PK
630.0
2.14
0.0
PK
1000.0
2.14
0.0
PK
1600.0
2.14
-0.25
PK
2500.0
2.14
-0.25
PK
4000.0
2.14
-0.5
PK
6300.0
2.14
-0.75
PK
10000.0
2.14
-0.5
PK
16000.0
2.14
-0.75
Download
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
Set preamp gain to: -0.2dB .
Type
Freq
Q
Gain
PK
20.0
4.32
0.0
PK
25.0
4.32
0.0
PK
31.0
4.32
0.0
PK
40.0
4.32
0.0
PK
50.0
4.32
0.25
PK
63.0
4.32
0.0
PK
80.0
4.32
-0.25
PK
100.0
4.32
0.0
PK
125.0
4.32
0.0
PK
160.0
4.32
0.0
PK
200.0
4.32
0.0
PK
250.0
4.32
0.0
PK
315.0
4.32
-0.25
PK
400.0
4.32
-0.25
PK
500.0
4.32
-0.25
PK
630.0
4.32
-0.25
PK
800.0
4.32
-0.25
PK
1000.0
4.32
0.0
PK
1250.0
4.32
0.0
PK
1600.0
4.32
-0.25
PK
2000.0
4.32
0.0
PK
2500.0
4.32
-0.25
PK
3150.0
4.32
-0.5
PK
4000.0
4.32
-0.5
PK
5000.0
4.32
-0.75
PK
6300.0
4.32
-0.75
PK
8000.0
4.32
-0.75
PK
10000.0
4.32
-0.5
PK
12000.0
4.32
-0.5
PK
16000.0
4.32
-0.75
PK
20000.0
4.32
0.0
Download
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
