What we know about the measurement:
Quality of the measurement data is
high .
Origin of the data is ASR.
Format of the data is
generated by a Klippel NFS
.
Sensitivity: 84.8 dB (avg. 100Hz-1kHz for 2.83V estimated at 1m )
-3dB (resp. -6db) point v.s. reference is at 117.2Hz (resp. 98.1Hz).
Reference level is normalised to 0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
Frequency deviation is 3.6dB over the same frequency range.
Directivity
Horizontal directivity
is (-40.0°, 50.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Vertical directivity
is (-50.0°, 40.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Tonality (Preference) Score
Note: The tonality (Preference) score
does not make sense for surround speakers. Don't give too much credits
to the value.
Tonality (Preference) Score is 1.58
and would be 5.21 with a
perfect subwoofer.
Details:
NBD: ON 0.606,
LW 0.523, SP
0.505, PIR
0.502; SM:
SP0.642,
PIR0.235; LFQ
0.835, LFX 101Hz
Tonality (Preference) Score is 4.84
with an EQ and would be 8.15 with a
perfect subwoofer and the same EQ.
Details:
NBD: ON 0.341,
LW 0.281, SP
0.266, PIR
0.252; SM:
SP0.952,
PIR0.892; LFQ 0.71, LFX 84Hz
Link to original Review: asr review .
.
AutomaticEQ (IIR)
Set preamp gain to: -2.6dB .
Type
Freq
Q
Gain
3
98.0
2.08
3.0
3
178.0
1.82
-2.38
3
976.0
2.9
-1.65
3
1333.0
2.14
3.0
3
2491.0
2.97
-1.94
3
7834.0
0.88
-4.37
3
11085.0
2.61
1.17
Download
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
maiky76@ASR LW (IIR)
Set preamp gain to: -3.3dB .
Type
Freq
Q
Gain
1
86.75
1.15
0.0
3
184.56
1.88
-2.84
3
947.17
1.73
-1.13
3
1360.98
2.23
3.83
3
2527.16
4.25
-1.03
3
7433.37
1.17
-3.23
3
13039.93
1.05
1.54
Download
These EQ is designed by ASR member maiky76. These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
maiky76@ASR (IIR)
Set preamp gain to: -3.4dB .
Type
Freq
Q
Gain
1
86.25
1.15
0.0
3
179.02
1.59
-3.03
3
1010.95
2.48
-2.04
3
1302.22
2.58
4.4
3
2514.16
3.25
-2.0
3
7518.11
0.98
-4.11
3
11528.5
2.59
1.11
Download
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
Graphic EQ 15 bands
Set preamp gain to: -0.7dB .
Type
Freq
Q
Gain
3
25.0
2.14
0.5
3
40.0
2.14
0.5
3
63.0
2.14
0.5
3
100.0
2.14
0.5
3
160.0
2.14
-0.25
3
250.0
2.14
-0.25
3
400.0
2.14
0.0
3
630.0
2.14
-0.25
3
1000.0
2.14
0.0
3
1600.0
2.14
0.25
3
2500.0
2.14
-0.5
3
4000.0
2.14
-0.5
3
6300.0
2.14
-0.75
3
10000.0
2.14
-0.75
3
16000.0
2.14
-0.5
Download
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
Set preamp gain to: -0.8dB .
Type
Freq
Q
Gain
3
20.0
4.32
0.0
3
25.0
4.32
0.5
3
31.0
4.32
0.5
3
40.0
4.32
0.5
3
50.0
4.32
0.5
3
63.0
4.32
0.5
3
80.0
4.32
0.5
3
100.0
4.32
0.5
3
125.0
4.32
0.25
3
160.0
4.32
-0.25
3
200.0
4.32
-0.25
3
250.0
4.32
-0.25
3
315.0
4.32
0.0
3
400.0
4.32
0.0
3
500.0
4.32
0.0
3
630.0
4.32
0.0
3
800.0
4.32
0.0
3
1000.0
4.32
0.0
3
1250.0
4.32
0.5
3
1600.0
4.32
0.5
3
2000.0
4.32
0.0
3
2500.0
4.32
-0.25
3
3150.0
4.32
-0.25
3
4000.0
4.32
-0.25
3
5000.0
4.32
-0.5
3
6300.0
4.32
-0.75
3
8000.0
4.32
-0.75
3
10000.0
4.32
-0.5
3
12000.0
4.32
-0.25
3
16000.0
4.32
-0.25
3
20000.0
4.32
0.0
Download
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
