What we know about the measurement:
- Quality of the measurement data is
unknown.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
a scanned image
.
-
Sensitivity: 82.9dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 51.9Hz (resp. 44.3Hz).
-
Reference level is normalised to 0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 4.6dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.05
and would be 5.16 with a
perfect subwoofer.
- Details:
NBD: ON 0.566,
LW 0.428, SP
0.446, PIR
0.409; SM:
SP0.112,
PIR0.047; LFQ
0.855, LFX 44Hz
- Tonality (Preference) Score is 6.71
with an EQ and would be 8.37 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.33,
LW 0.231, SP
0.322, PIR
0.222; SM:
SP0.943,
PIR0.939; LFQ 0.855, LFX 35Hz
-
Link to original Review: eac review.
Links to other reviews: asr review
.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
32.0 |
0.39 |
2.99 |
| PK |
83.0 |
1.66 |
-4.13 |
| PK |
344.0 |
2.8 |
1.18 |
| PK |
540.0 |
2.99 |
2.99 |
| PK |
1429.0 |
2.72 |
2.93 |
| PK |
5934.0 |
0.48 |
-5.9 |
| PK |
12736.0 |
1.07 |
-4.59 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
-0.5 |
| PK |
6300.0 |
2.14 |
-0.75 |
| PK |
10000.0 |
2.14 |
-0.75 |
| PK |
16000.0 |
2.14 |
-0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.0 |
| PK |
80.0 |
4.32 |
-0.25 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
-0.25 |
| PK |
2500.0 |
4.32 |
-0.5 |
| PK |
3150.0 |
4.32 |
-0.5 |
| PK |
4000.0 |
4.32 |
-0.75 |
| PK |
5000.0 |
4.32 |
-0.75 |
| PK |
6300.0 |
4.32 |
-0.75 |
| PK |
8000.0 |
4.32 |
-0.75 |
| PK |
10000.0 |
4.32 |
-1.0 |
| PK |
12000.0 |
4.32 |
-1.0 |
| PK |
16000.0 |
4.32 |
-0.5 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
