What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
-3dB (resp. -6db) point v.s. reference is at 79.2Hz (resp. 55.3Hz).
-
Reference level is normalised to 0.6dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.8dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.39
and would be 6.92 with a
perfect subwoofer.
- Details:
NBD: ON 0.53,
LW 0.327, SP
0.447, PIR
0.377; SM:
SP0.827,
PIR0.728; LFQ
2.535, LFX 56Hz
- Tonality (Preference) Score is 5.49
with an EQ and would be 7.78 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.51,
LW 0.28, SP
0.352, PIR
0.244; SM:
SP0.907,
PIR0.904; LFQ 2.535, LFX 49Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| HS |
99.0 |
0.67 |
-2.99 |
| PK |
280.0 |
1.54 |
2.71 |
| PK |
378.0 |
0.3 |
-3.0 |
| PK |
739.0 |
1.47 |
2.07 |
| PK |
1220.0 |
2.86 |
2.41 |
| PK |
1948.0 |
2.85 |
1.65 |
| PK |
3555.0 |
1.27 |
-0.56 |
| PK |
6276.0 |
2.87 |
-0.81 |
| LS |
14473.0 |
0.51 |
3.0 |
|
Download
|
This EQ optimise the Harman score and is a good start for far field listening like in your living room.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.5 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
-0.25 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
-0.25 |
|
Download
|
This EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.5 |
| PK |
100.0 |
4.32 |
0.25 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.25 |
| PK |
315.0 |
4.32 |
0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.5 |
| PK |
1000.0 |
4.32 |
0.5 |
| PK |
1250.0 |
4.32 |
0.5 |
| PK |
1600.0 |
4.32 |
0.25 |
| PK |
2000.0 |
4.32 |
0.5 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
0.25 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.25 |
| PK |
10000.0 |
4.32 |
0.25 |
| PK |
12000.0 |
4.32 |
0.25 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
This EQ is designed for a 31 bands graphical EQ.
EQ
Target v.s. EQ
Histogram of errors
Listening Window (fullrange)
Predicted In-Room Response (fullrange)
Comparison betweens various EQs
|
