What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 39.6Hz (resp. 36.6Hz).
-
Reference level is normalised to -0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.7dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 2.25
and would be 3.91 with a
perfect subwoofer.
- Details:
NBD: ON 0.907,
LW 0.852, SP
0.862, PIR
0.845; SM:
SP0.734,
PIR0.44; LFQ
2.251, LFX 35Hz
- Tonality (Preference) Score is 3.33
with an EQ and would be 4.98 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.778,
LW 0.714, SP
0.805, PIR
0.739; SM:
SP0.833,
PIR0.627; LFQ 2.251, LFX 35Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -1.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
36.0 |
2.9 |
2.98 |
| 3 |
52.0 |
0.26 |
-2.07 |
| 3 |
139.0 |
2.99 |
3.0 |
| 3 |
409.0 |
1.11 |
-3.16 |
| 3 |
643.0 |
1.17 |
2.8 |
| 3 |
4654.0 |
2.35 |
-2.87 |
| 3 |
14134.0 |
1.02 |
-8.99 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
AutomaticEQ LW (IIR)
|
|
Set preamp gain to: -4.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
39.0 |
3.0 |
0.31 |
| 3 |
39.0 |
2.78 |
2.64 |
| 3 |
54.0 |
1.08 |
-2.69 |
| 3 |
378.0 |
1.17 |
-2.99 |
| 3 |
714.0 |
1.58 |
2.75 |
| 3 |
2909.0 |
2.78 |
2.74 |
| 3 |
3008.0 |
0.25 |
1.37 |
|
Download
|
These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
|
AutomaticEQ Score (IIR)
|
|
Set preamp gain to: -3.6dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
39.0 |
2.74 |
2.68 |
| 3 |
56.0 |
1.72 |
-2.94 |
| 3 |
391.0 |
1.2 |
-2.62 |
| 3 |
668.0 |
1.93 |
2.82 |
| 3 |
1491.0 |
0.81 |
1.81 |
| 3 |
3008.0 |
2.94 |
2.97 |
| 3 |
13537.0 |
1.07 |
-3.0 |
|
Download
|
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.0 |
| 3 |
40.0 |
2.14 |
0.0 |
| 3 |
63.0 |
2.14 |
-0.25 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
-0.25 |
| 3 |
400.0 |
2.14 |
-0.25 |
| 3 |
630.0 |
2.14 |
0.25 |
| 3 |
1000.0 |
2.14 |
0.25 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
0.25 |
| 3 |
4000.0 |
2.14 |
-0.25 |
| 3 |
6300.0 |
2.14 |
0.0 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
-0.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.9dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.0 |
| 3 |
31.0 |
4.32 |
0.0 |
| 3 |
40.0 |
4.32 |
0.0 |
| 3 |
50.0 |
4.32 |
-0.25 |
| 3 |
63.0 |
4.32 |
-0.25 |
| 3 |
80.0 |
4.32 |
-0.25 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.25 |
| 3 |
160.0 |
4.32 |
0.25 |
| 3 |
200.0 |
4.32 |
-0.25 |
| 3 |
250.0 |
4.32 |
-0.25 |
| 3 |
315.0 |
4.32 |
-0.25 |
| 3 |
400.0 |
4.32 |
-0.25 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.25 |
| 3 |
800.0 |
4.32 |
0.25 |
| 3 |
1000.0 |
4.32 |
0.25 |
| 3 |
1250.0 |
4.32 |
0.25 |
| 3 |
1600.0 |
4.32 |
0.5 |
| 3 |
2000.0 |
4.32 |
0.5 |
| 3 |
2500.0 |
4.32 |
0.5 |
| 3 |
3150.0 |
4.32 |
0.75 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.25 |
| 3 |
6300.0 |
4.32 |
0.25 |
| 3 |
8000.0 |
4.32 |
0.25 |
| 3 |
10000.0 |
4.32 |
0.25 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
-0.5 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
