What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
Sensitivity: 90.1dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 99.5Hz (resp. 82.0Hz).
-
Reference level is normalised to 0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.5dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.87
and would be 8.12 with a
perfect subwoofer.
- Details:
NBD: ON 0.347,
LW 0.273, SP
0.311, PIR
0.216; SM:
SP0.887,
PIR0.841; LFQ
1.707, LFX 82Hz
- Tonality (Preference) Score is 5.94
with an EQ and would be 8.43 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.251,
LW 0.194, SP
0.268, PIR
0.156; SM:
SP0.844,
PIR0.794; LFQ 1.53, LFX 54Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -6.4dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
99.0 |
0.79 |
2.92 |
| PK |
99.0 |
0.3 |
1.64 |
| PK |
138.0 |
1.08 |
-2.9 |
| PK |
262.0 |
2.72 |
0.68 |
| PK |
584.0 |
0.26 |
-2.66 |
| PK |
625.0 |
0.28 |
-1.36 |
| PK |
1394.0 |
2.96 |
0.86 |
| PK |
3676.0 |
1.66 |
-0.91 |
| LS |
16000.0 |
0.57 |
2.85 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.75 |
| PK |
40.0 |
2.14 |
0.75 |
| PK |
63.0 |
2.14 |
0.75 |
| PK |
100.0 |
2.14 |
0.75 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
0.25 |
| PK |
10000.0 |
2.14 |
0.25 |
| PK |
16000.0 |
2.14 |
1.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.75 |
| PK |
31.0 |
4.32 |
0.75 |
| PK |
40.0 |
4.32 |
0.75 |
| PK |
50.0 |
4.32 |
0.75 |
| PK |
63.0 |
4.32 |
0.75 |
| PK |
80.0 |
4.32 |
0.75 |
| PK |
100.0 |
4.32 |
0.75 |
| PK |
125.0 |
4.32 |
0.25 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.25 |
| PK |
250.0 |
4.32 |
0.25 |
| PK |
315.0 |
4.32 |
0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
-0.25 |
| PK |
2000.0 |
4.32 |
-0.25 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
0.25 |
| PK |
6300.0 |
4.32 |
0.25 |
| PK |
8000.0 |
4.32 |
0.25 |
| PK |
10000.0 |
4.32 |
0.25 |
| PK |
12000.0 |
4.32 |
0.25 |
| PK |
16000.0 |
4.32 |
1.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
