What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
Sensitivity: 90.2dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 89.1Hz (resp. 70.9Hz).
-
Reference level is normalised to 0.8dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.6dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.37
and would be 8.18 with a
perfect subwoofer.
- Details:
NBD: ON 0.364,
LW 0.298, SP
0.295, PIR
0.214; SM:
SP0.897,
PIR0.882; LFQ
2.229, LFX 64Hz
- Tonality (Preference) Score is 6.34
with an EQ and would be 8.74 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.312,
LW 0.251, SP
0.247, PIR
0.143; SM:
SP0.957,
PIR0.98; LFQ 2.229, LFX 52Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
108.0 |
1.89 |
3.0 |
| PK |
433.0 |
2.97 |
-1.13 |
| PK |
15512.0 |
0.79 |
2.28 |
| PK |
824.0 |
2.88 |
1.15 |
| PK |
164.0 |
2.98 |
-0.76 |
| PK |
2590.0 |
2.98 |
-0.75 |
| PK |
12118.0 |
2.99 |
-0.75 |
| PK |
520.0 |
2.98 |
-0.75 |
| PK |
1629.0 |
3.0 |
-0.75 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.75 |
| PK |
40.0 |
2.14 |
0.75 |
| PK |
63.0 |
2.14 |
0.75 |
| PK |
100.0 |
2.14 |
0.5 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
-0.25 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
0.0 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.75 |
| PK |
31.0 |
4.32 |
0.75 |
| PK |
40.0 |
4.32 |
0.75 |
| PK |
50.0 |
4.32 |
0.75 |
| PK |
63.0 |
4.32 |
0.75 |
| PK |
80.0 |
4.32 |
0.75 |
| PK |
100.0 |
4.32 |
0.5 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
-0.25 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.25 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
-0.25 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.5 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
