What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
Sensitivity: 90.3dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
-
-3dB (resp. -6db) point v.s. reference is at 67.1Hz (resp. 53.4Hz).
-
Reference level is normalised to 0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.9dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.67
and would be 6.35 with a
perfect subwoofer.
- Details:
NBD: ON 0.593,
LW 0.475, SP
0.522, PIR
0.437; SM:
SP0.786,
PIR0.626; LFQ
1.152, LFX 35Hz
- Tonality (Preference) Score is 6.23
with an EQ and would be 7.62 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.486,
LW 0.374, SP
0.376, PIR
0.3; SM:
SP0.921,
PIR0.884; LFQ 1.359, LFX 30Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| 5 |
67.0 |
1.01 |
2.94 |
| 3 |
342.0 |
2.86 |
-0.25 |
| 3 |
432.0 |
2.8 |
2.18 |
| 3 |
547.0 |
1.75 |
-2.79 |
| 3 |
933.0 |
2.54 |
1.12 |
| 3 |
2014.0 |
2.59 |
1.97 |
| 3 |
4202.0 |
2.98 |
-2.13 |
| 3 |
9372.0 |
2.87 |
-2.39 |
| 6 |
13537.0 |
0.55 |
-2.63 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
0.5 |
| 3 |
100.0 |
2.14 |
-0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.25 |
| 3 |
400.0 |
2.14 |
0.25 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
0.5 |
| 3 |
1600.0 |
2.14 |
0.5 |
| 3 |
2500.0 |
2.14 |
0.5 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
0.25 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.5 |
| 3 |
31.0 |
4.32 |
0.5 |
| 3 |
40.0 |
4.32 |
0.5 |
| 3 |
50.0 |
4.32 |
0.5 |
| 3 |
63.0 |
4.32 |
0.5 |
| 3 |
80.0 |
4.32 |
0.25 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
-0.25 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
-0.5 |
| 3 |
630.0 |
4.32 |
-0.5 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
0.0 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.25 |
| 3 |
2500.0 |
4.32 |
0.25 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
-0.25 |
| 3 |
5000.0 |
4.32 |
0.25 |
| 3 |
6300.0 |
4.32 |
0.0 |
| 3 |
8000.0 |
4.32 |
0.75 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
