What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
Sensitivity: 84.3dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 97.4Hz (resp. 66.2Hz).
-
Reference level is normalised to 0.6dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.1dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.13
and would be 7.93 with a
perfect subwoofer.
- Details:
NBD: ON 0.293,
LW 0.239, SP
0.283, PIR
0.236; SM:
SP0.873,
PIR0.727; LFQ
0.74, LFX 64Hz
- Tonality (Preference) Score is 6.42
with an EQ and would be 8.92 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.221,
LW 0.133, SP
0.229, PIR
0.146; SM:
SP0.965,
PIR0.958; LFQ 0.74, LFX 54Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -4.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
54.0 |
2.69 |
2.98 |
| PK |
98.0 |
0.41 |
2.3 |
| PK |
540.0 |
0.25 |
-1.12 |
| PK |
1887.0 |
2.97 |
1.14 |
| PK |
3779.0 |
2.85 |
-1.21 |
| PK |
5934.0 |
1.85 |
-1.83 |
| PK |
9648.0 |
2.99 |
-2.26 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.5 |
| PK |
160.0 |
2.14 |
0.25 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.25 |
| PK |
10000.0 |
2.14 |
-0.25 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.5 |
| PK |
100.0 |
4.32 |
0.5 |
| PK |
125.0 |
4.32 |
0.25 |
| PK |
160.0 |
4.32 |
0.25 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.25 |
| PK |
2000.0 |
4.32 |
0.25 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
-0.25 |
| PK |
12000.0 |
4.32 |
0.25 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
