What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 47.6Hz (resp. 42.5Hz).
-
Reference level is normalised to -0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 7.8dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.69
and would be 6.71 with a
perfect subwoofer.
- Details:
NBD: ON 0.508,
LW 0.482, SP
0.411, PIR
0.421; SM:
SP0.85,
PIR0.668; LFQ
0.601, LFX 42Hz
- Tonality (Preference) Score is 6.21
with an EQ and would be 8.09 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.355,
LW 0.322, SP
0.292, PIR
0.255; SM:
SP0.94,
PIR0.887; LFQ 0.601, LFX 39Hz
- Link to Original review.
-
Vendor specifications:
- Size
- Width 151mm
- Height 268mm
- Depth 274mm
- Weight 5.68kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
47.0 |
0.36 |
1.49 |
| PK |
153.0 |
1.36 |
-0.96 |
| PK |
280.0 |
0.65 |
-1.57 |
| PK |
790.0 |
2.99 |
2.8 |
| PK |
965.0 |
2.63 |
-2.23 |
| PK |
1348.0 |
2.45 |
-2.46 |
| PK |
1884.0 |
2.64 |
1.02 |
| PK |
6709.0 |
2.53 |
-1.9 |
| LS |
8766.0 |
0.91 |
1.62 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -4.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
435.0 |
20.0 |
-0.5 |
| PK |
565.0 |
3.5 |
1.3 |
| PK |
758.0 |
23.0 |
4.4 |
| PK |
1000.0 |
5.0 |
-1.5 |
| PK |
1311.0 |
5.0 |
9.2 |
| PK |
1321.0 |
4.979 |
-11.7 |
| PK |
1773.0 |
5.0 |
3.8 |
| PK |
1850.0 |
5.0 |
-5.8 |
| PK |
1954.0 |
5.0 |
6.4 |
| PK |
2039.0 |
5.0 |
-4.1 |
| PK |
2305.0 |
2.888 |
6.0 |
| PK |
2376.0 |
4.995 |
-5.3 |
| PK |
5049.0 |
3.063 |
1.5 |
| PK |
7910.0 |
5.0 |
1.9 |
| PK |
9443.0 |
1.0 |
-6.1 |
| PK |
9834.0 |
2.724 |
5.7 |
| PK |
12400.0 |
9.0 |
-0.5 |
| PK |
13500.0 |
11.0 |
1.5 |
| PK |
15100.0 |
7.0 |
-1.3 |
| PK |
16920.0 |
4.0 |
2.7 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
-0.5 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
0.25 |
| PK |
100.0 |
4.32 |
0.25 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
-0.5 |
| PK |
1250.0 |
4.32 |
-0.5 |
| PK |
1600.0 |
4.32 |
-0.25 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
-0.25 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.5 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
-0.5 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
