What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 71.8Hz (resp. 62.3Hz).
-
Reference level is normalised to 0.4dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 4.9dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-60.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 1.65
and would be 4.38 with a
perfect subwoofer.
- Details:
NBD: ON 0.924,
LW 0.648, SP
0.515, PIR
0.52; SM:
SP0.576,
PIR0.24; LFQ
0.135, LFX 62Hz
- Tonality (Preference) Score is 4.17
with an EQ and would be 6.71 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.758,
LW 0.51, SP
0.383, PIR
0.362; SM:
SP0.906,
PIR0.864; LFQ 0.135, LFX 56Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
58.0 |
1.97 |
2.99 |
| PK |
155.0 |
0.85 |
-2.28 |
| PK |
356.0 |
2.95 |
1.94 |
| PK |
579.0 |
1.42 |
1.05 |
| PK |
3779.0 |
2.32 |
2.81 |
| PK |
4818.0 |
1.54 |
-6.94 |
| PK |
15150.0 |
1.11 |
-7.47 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
AutomaticEQ LW (IIR)
|
|
Set preamp gain to: -2.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
69.0 |
2.97 |
2.88 |
| PK |
172.0 |
0.71 |
-3.16 |
| PK |
356.0 |
0.68 |
2.34 |
| PK |
4818.0 |
2.94 |
-1.83 |
| PK |
7566.0 |
2.95 |
-2.05 |
| PK |
9989.0 |
2.99 |
2.8 |
| PK |
14633.0 |
1.58 |
-5.08 |
|
Download
|
These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
387.0 |
7.0 |
1.4 |
| PK |
541.0 |
2.485 |
0.9 |
| PK |
835.0 |
10.0 |
0.6 |
| PK |
1818.0 |
16.0 |
-1.8 |
| PK |
2643.0 |
5.0 |
-1.3 |
| PK |
2951.0 |
5.0 |
-9.8 |
| PK |
3043.0 |
5.0 |
11.9 |
| PK |
3959.0 |
4.984 |
3.1 |
| PK |
4728.0 |
1.771 |
-6.9 |
| PK |
6203.0 |
2.717 |
-1.4 |
| PK |
7216.0 |
4.612 |
-4.4 |
| PK |
8695.0 |
2.733 |
-8.4 |
| PK |
9877.0 |
1.275 |
12.0 |
| PK |
11157.0 |
2.479 |
-7.0 |
| PK |
13185.0 |
5.0 |
-1.3 |
| PK |
14572.0 |
5.0 |
-0.6 |
| PK |
14802.0 |
1.017 |
-7.4 |
| PK |
16211.0 |
3.445 |
-1.1 |
| PK |
17769.0 |
5.0 |
-1.5 |
| PK |
19060.0 |
5.0 |
1.6 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
-0.5 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
-0.5 |
| PK |
4000.0 |
2.14 |
-0.5 |
| PK |
6300.0 |
2.14 |
-1.0 |
| PK |
10000.0 |
2.14 |
-0.5 |
| PK |
16000.0 |
2.14 |
-1.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
-0.25 |
| PK |
2500.0 |
4.32 |
-0.5 |
| PK |
3150.0 |
4.32 |
0.25 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.75 |
| PK |
6300.0 |
4.32 |
-0.5 |
| PK |
8000.0 |
4.32 |
-0.5 |
| PK |
10000.0 |
4.32 |
0.25 |
| PK |
12000.0 |
4.32 |
-0.5 |
| PK |
16000.0 |
4.32 |
-1.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
