What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 76.9dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
-
-3dB (resp. -6db) point v.s. reference is at 63.0Hz (resp. 58.6Hz).
-
Reference level is normalised to 1.8dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 12.2dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-10.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for surround speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is -0.15
and would be 2.37 with a
perfect subwoofer.
- Details:
NBD: ON 1.043,
LW 1.029, SP
0.962, PIR
0.971; SM:
SP0.0,
PIR0.082; LFQ
0.758, LFX 55Hz
- Tonality (Preference) Score is 2.9
with an EQ and would be 5.15 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.762,
LW 0.716, SP
0.336, PIR
0.37; SM:
SP0.618,
PIR0.207; LFQ 0.758, LFX 48Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -0.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
126.0 |
0.34 |
-3.0 |
| 3 |
6184.0 |
0.25 |
-6.0 |
| 3 |
648.0 |
2.09 |
2.98 |
| 3 |
1532.0 |
2.97 |
2.97 |
| 3 |
10434.0 |
0.25 |
-4.09 |
| 3 |
236.0 |
1.43 |
-5.26 |
| 3 |
1058.0 |
3.0 |
-5.84 |
| 3 |
2591.0 |
1.85 |
-3.46 |
| 3 |
1060.0 |
3.0 |
-4.97 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.0 |
| 3 |
40.0 |
2.14 |
0.0 |
| 3 |
63.0 |
2.14 |
0.0 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
-0.25 |
| 3 |
250.0 |
2.14 |
-0.5 |
| 3 |
400.0 |
2.14 |
0.25 |
| 3 |
630.0 |
2.14 |
1.0 |
| 3 |
1000.0 |
2.14 |
0.0 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
-0.75 |
| 3 |
4000.0 |
2.14 |
-0.75 |
| 3 |
6300.0 |
2.14 |
-1.0 |
| 3 |
10000.0 |
2.14 |
-0.5 |
| 3 |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.0 |
| 3 |
31.0 |
4.32 |
0.0 |
| 3 |
40.0 |
4.32 |
0.0 |
| 3 |
50.0 |
4.32 |
0.0 |
| 3 |
63.0 |
4.32 |
0.0 |
| 3 |
80.0 |
4.32 |
0.0 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
-0.25 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
-0.5 |
| 3 |
250.0 |
4.32 |
-0.5 |
| 3 |
315.0 |
4.32 |
-0.25 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.25 |
| 3 |
630.0 |
4.32 |
0.5 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
-1.0 |
| 3 |
1250.0 |
4.32 |
-0.75 |
| 3 |
1600.0 |
4.32 |
-0.25 |
| 3 |
2000.0 |
4.32 |
-0.75 |
| 3 |
2500.0 |
4.32 |
-1.0 |
| 3 |
3150.0 |
4.32 |
-1.25 |
| 3 |
4000.0 |
4.32 |
-1.0 |
| 3 |
5000.0 |
4.32 |
-1.0 |
| 3 |
6300.0 |
4.32 |
-1.0 |
| 3 |
8000.0 |
4.32 |
-1.0 |
| 3 |
10000.0 |
4.32 |
-0.75 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
-0.5 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
