What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is Infinity.
-
Format of the data is
a scanned image
.
-
Sensitivity: 86.1dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 87.2Hz (resp. 59.6Hz).
-
Reference level is normalised to 0.9dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.6dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.07
and would be 7.5 with a
perfect subwoofer.
- Details:
NBD: ON 0.356,
LW 0.334, SP
0.273, PIR
0.279; SM:
SP0.858,
PIR0.665; LFQ
0.458, LFX 53Hz
- Tonality (Preference) Score is 6.4
with an EQ and would be 8.54 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.299,
LW 0.233, SP
0.246, PIR
0.206; SM:
SP0.964,
PIR0.958; LFQ 0.787, LFX 45Hz
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
46.0 |
0.62 |
2.97 |
| PK |
121.0 |
1.32 |
-1.59 |
| PK |
344.0 |
2.9 |
0.47 |
| PK |
1586.0 |
0.95 |
-2.4 |
| PK |
2579.0 |
1.43 |
1.75 |
| PK |
4989.0 |
1.69 |
-1.07 |
| PK |
16239.0 |
0.25 |
-3.22 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
maiky76@ASR (IIR)
|
|
Set preamp gain to: -1.8dB.
|
| Type |
Freq |
Q |
Gain |
| HP |
54.6 |
1.16 |
0.0 |
| PK |
120.0 |
1.6 |
-2.0 |
| PK |
962.0 |
6.0 |
-1.48 |
| PK |
1343.0 |
5.2 |
-2.1 |
| PK |
1830.0 |
3.11 |
-1.55 |
| PK |
2608.0 |
1.14 |
2.17 |
| PK |
4552.0 |
1.0 |
-1.0 |
| PK |
14244.0 |
0.97 |
-1.66 |
|
Download
|
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.5 |
| PK |
16000.0 |
2.14 |
-0.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.5 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
-0.5 |
| PK |
1250.0 |
4.32 |
-0.5 |
| PK |
1600.0 |
4.32 |
-0.5 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.25 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
-0.25 |
| PK |
12000.0 |
4.32 |
-0.25 |
| PK |
16000.0 |
4.32 |
-0.5 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
