What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is Infinity.
-
Format of the data is
a scanned image
.
-
Sensitivity: 85.2dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 23.1Hz (resp. 20.0Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.5dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 7.23
and would be 7.83 with a
perfect subwoofer.
- Details:
NBD: ON 0.291,
LW 0.207, SP
0.375, PIR
0.268; SM:
SP0.774,
PIR0.724; LFQ
0.769, LFX 20Hz
- Tonality (Preference) Score is 7.96
with an EQ and would be 8.56 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.289,
LW 0.201, SP
0.291, PIR
0.189; SM:
SP0.91,
PIR0.933; LFQ 0.769, LFX 20Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
37.0 |
2.93 |
-3.46 |
| PK |
83.0 |
2.83 |
-1.47 |
| PK |
409.0 |
1.43 |
0.84 |
| PK |
2491.0 |
1.94 |
1.41 |
| PK |
2670.0 |
0.58 |
-1.27 |
| PK |
4654.0 |
1.93 |
-1.3 |
| PK |
9319.0 |
1.68 |
-0.57 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.0 |
| PK |
40.0 |
2.14 |
-0.5 |
| PK |
63.0 |
2.14 |
-0.25 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.25 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
0.0 |
| PK |
10000.0 |
2.14 |
0.25 |
| PK |
16000.0 |
2.14 |
0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.0 |
| PK |
31.0 |
4.32 |
-0.25 |
| PK |
40.0 |
4.32 |
-0.5 |
| PK |
50.0 |
4.32 |
-0.25 |
| PK |
63.0 |
4.32 |
-0.25 |
| PK |
80.0 |
4.32 |
-0.25 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
-0.25 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
-0.25 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
