What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Infinity.
-
Format of the data is
a scanned image
.
-
Warning: this measurement was already process with an equalizer.
-
Sensitivity: 89.9dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
-
-3dB (resp. -6db) point v.s. reference is at 20.3Hz (resp. 20.3Hz).
-
Reference level is normalised to 0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 0.9dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 6.829999999999999
and would be 7.46 with a
perfect subwoofer.
- Details:
NBD: ON 0.234,
LW 0.248, SP
0.229, PIR
0.196; SM:
SP0.942,
PIR0.928; LFQ
1.909, LFX 20Hz
- Tonality (Preference) Score is 8.32
with an EQ and would be 8.94 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.196,
LW 0.203, SP
0.225, PIR
0.161; SM:
SP0.95,
PIR0.963; LFQ 1.909, LFX 20Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -0.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
32.0 |
2.99 |
-3.27 |
| 3 |
102.0 |
2.84 |
-1.19 |
| 3 |
243.0 |
1.82 |
-0.8 |
| 3 |
540.0 |
2.96 |
-0.33 |
| 3 |
1202.0 |
3.0 |
-0.59 |
| 3 |
2168.0 |
2.18 |
-0.84 |
| 3 |
10341.0 |
1.71 |
-1.97 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.0 |
| 3 |
40.0 |
2.14 |
-0.25 |
| 3 |
63.0 |
2.14 |
0.0 |
| 3 |
100.0 |
2.14 |
-0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
-0.25 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
0.0 |
| 3 |
1600.0 |
2.14 |
0.0 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
0.0 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
-0.25 |
| 3 |
31.0 |
4.32 |
-0.5 |
| 3 |
40.0 |
4.32 |
-0.5 |
| 3 |
50.0 |
4.32 |
-0.25 |
| 3 |
63.0 |
4.32 |
-0.25 |
| 3 |
80.0 |
4.32 |
-0.25 |
| 3 |
100.0 |
4.32 |
-0.25 |
| 3 |
125.0 |
4.32 |
-0.25 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
-0.25 |
| 3 |
250.0 |
4.32 |
-0.25 |
| 3 |
315.0 |
4.32 |
-0.25 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
0.0 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
-0.25 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.0 |
| 3 |
6300.0 |
4.32 |
0.0 |
| 3 |
8000.0 |
4.32 |
0.0 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
0.0 |
| 3 |
16000.0 |
4.32 |
0.25 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
