What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 87.9Hz (resp. 77.6Hz).
-
Reference level is normalised to 0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.5dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 70.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-50.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for inwall speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is 1.89
and would be 5.14 with a
perfect subwoofer.
- Details:
NBD: ON 0.685,
LW 0.659, SP
0.752, PIR
0.681; SM:
SP0.677,
PIR0.519; LFQ
2.279, LFX 82Hz
- Tonality (Preference) Score is 3.81
with an EQ and would be 6.88 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.538,
LW 0.504, SP
0.546, PIR
0.476; SM:
SP0.891,
PIR0.848; LFQ 2.279, LFX 74Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.4dB.
|
| Type |
Freq |
Q |
Gain |
| 5 |
87.0 |
0.65 |
2.44 |
| 3 |
418.0 |
2.52 |
2.04 |
| 3 |
584.0 |
2.92 |
-1.34 |
| 3 |
1032.0 |
2.92 |
1.96 |
| 3 |
2153.0 |
2.86 |
1.52 |
| 3 |
2721.0 |
1.71 |
-2.91 |
| 3 |
6276.0 |
2.96 |
-2.81 |
| 3 |
7417.0 |
1.15 |
2.3 |
| 3 |
11454.0 |
0.86 |
-3.0 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
maiky76@ASR (IIR)
|
|
Set preamp gain to: -0.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
0.1 |
1.12 |
0.0 |
| 3 |
147.92 |
1.68 |
-3.21 |
| 3 |
600.49 |
3.93 |
-3.46 |
| 3 |
850.15 |
6.99 |
-2.32 |
| 3 |
1403.84 |
2.82 |
-1.45 |
| 3 |
2140.43 |
5.4 |
0.74 |
| 3 |
2520.36 |
3.67 |
-2.07 |
| 3 |
3227.17 |
1.55 |
-3.31 |
| 3 |
6314.23 |
5.79 |
-2.76 |
| 3 |
11605.83 |
1.13 |
-4.42 |
|
Download
|
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.75 |
| 3 |
40.0 |
2.14 |
0.75 |
| 3 |
63.0 |
2.14 |
0.75 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
-0.25 |
| 3 |
250.0 |
2.14 |
0.5 |
| 3 |
400.0 |
2.14 |
0.5 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
0.5 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
-0.25 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
-0.25 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.75 |
| 3 |
31.0 |
4.32 |
0.75 |
| 3 |
40.0 |
4.32 |
0.75 |
| 3 |
50.0 |
4.32 |
0.75 |
| 3 |
63.0 |
4.32 |
0.75 |
| 3 |
80.0 |
4.32 |
0.75 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
-0.25 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.5 |
| 3 |
315.0 |
4.32 |
0.25 |
| 3 |
400.0 |
4.32 |
0.5 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
0.5 |
| 3 |
1250.0 |
4.32 |
0.25 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
-0.25 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.0 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
0.0 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
