What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 55.7Hz (resp. 51.3Hz).
-
Reference level is normalised to -0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.9dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 6.24
and would be 8.5 with a
perfect subwoofer.
- Details:
NBD: ON 0.23,
LW 0.217, SP
0.294, PIR
0.235; SM:
SP0.937,
PIR0.903; LFQ
0.527, LFX 48Hz
- Tonality (Preference) Score is 6.77
with an EQ and would be 8.97 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.204,
LW 0.168, SP
0.206, PIR
0.152; SM:
SP0.977,
PIR0.97; LFQ 0.707, LFX 46Hz
- Link to Original review.
-
Vendor specifications:
- Size
- Width 189mm
- Height 299mm
- Depth 178mm
- Weight 5kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
68.0 |
0.3 |
2.93 |
| PK |
125.0 |
0.7 |
-1.2 |
| PK |
237.0 |
0.76 |
1.29 |
| PK |
790.0 |
1.81 |
-1.06 |
| PK |
998.0 |
1.48 |
1.27 |
| PK |
1704.0 |
2.21 |
-1.35 |
| PK |
2461.0 |
2.38 |
1.45 |
| PK |
2909.0 |
1.22 |
1.68 |
| PK |
11843.0 |
0.93 |
1.56 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -1.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
355.0 |
17.0 |
0.3 |
| PK |
541.0 |
20.0 |
0.8 |
| PK |
585.0 |
8.0 |
-0.4 |
| PK |
674.0 |
15.0 |
0.5 |
| PK |
690.0 |
2.048 |
-1.1 |
| PK |
782.0 |
25.0 |
-0.5 |
| PK |
958.0 |
5.0 |
0.2 |
| PK |
1022.0 |
20.0 |
-0.4 |
| PK |
1105.0 |
15.0 |
0.6 |
| PK |
1205.0 |
20.0 |
0.4 |
| PK |
1658.0 |
18.0 |
0.8 |
| PK |
1835.0 |
1.79 |
-3.0 |
| PK |
1890.0 |
9.0 |
0.6 |
| PK |
2142.0 |
25.0 |
0.4 |
| PK |
2300.0 |
1.358 |
3.2 |
| PK |
3200.0 |
6.0 |
0.4 |
| PK |
4380.0 |
4.5 |
-0.2 |
| PK |
5570.0 |
8.0 |
0.7 |
| PK |
6437.0 |
1.0 |
-1.0 |
| PK |
11200.0 |
5.8 |
0.5 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
-0.25 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.0 |
| PK |
80.0 |
4.32 |
-0.25 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
-0.25 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.25 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
