What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Princeton.
-
Format of the data is
.
-
Sensitivity: 86.4dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
Reference level is normalised to 0.4dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is -1.69
and would be 4.97 with a
perfect subwoofer.
- Details:
NBD: ON 0.745,
LW 0.527, SP
0.578, PIR
0.552; SM:
SP0.551,
PIR0.343; LFQ
10.0, LFX 509Hz
- Tonality (Preference) Score is 0.23
with an EQ and would be 6.89 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.611,
LW 0.372, SP
0.428, PIR
0.388; SM:
SP0.733,
PIR0.818; LFQ 10.0, LFX 509Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
40.0 |
0.29 |
2.59 |
| 3 |
105.0 |
2.78 |
-5.52 |
| 3 |
504.0 |
2.28 |
-7.49 |
| 3 |
689.0 |
0.75 |
-6.37 |
| 3 |
2406.0 |
1.77 |
-1.2 |
| 3 |
3405.0 |
0.75 |
-3.91 |
| 3 |
13652.0 |
2.85 |
0.67 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.0 |
| 3 |
40.0 |
2.14 |
0.0 |
| 3 |
63.0 |
2.14 |
0.0 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.75 |
| 3 |
1000.0 |
2.14 |
0.25 |
| 3 |
1600.0 |
2.14 |
0.75 |
| 3 |
2500.0 |
2.14 |
0.25 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
0.75 |
| 3 |
10000.0 |
2.14 |
1.0 |
| 3 |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.0 |
| 3 |
31.0 |
4.32 |
0.0 |
| 3 |
40.0 |
4.32 |
0.0 |
| 3 |
50.0 |
4.32 |
0.0 |
| 3 |
63.0 |
4.32 |
0.0 |
| 3 |
80.0 |
4.32 |
0.0 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.25 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
0.0 |
| 3 |
1250.0 |
4.32 |
0.25 |
| 3 |
1600.0 |
4.32 |
0.25 |
| 3 |
2000.0 |
4.32 |
0.25 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.25 |
| 3 |
6300.0 |
4.32 |
0.25 |
| 3 |
8000.0 |
4.32 |
0.25 |
| 3 |
10000.0 |
4.32 |
0.25 |
| 3 |
12000.0 |
4.32 |
0.25 |
| 3 |
16000.0 |
4.32 |
-0.25 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
